ASTM A335 P22 Seamless Pipe Beveled Plain End SCH 5 - SCH XXS Alloy Steel
ASTM A335 P22 Seamless Pipe Beveled Plain End SCH 5 - SCH XXS Alloy Steel
ASTM A335 P22 Seamless Pipe Beveled Plain End SCH 5 - SCH XXS Alloy Steel
ASTM A335 P22 Seamless Pipe Beveled Plain End SCH 5 - SCH XXS Alloy Steel
Specifications
Brand Name :
HT
Model Number :
ASTM A335 P22 Seamless Pipe Beveled Plain End SCH 5 - SCH XXS Alloy Steel
Certification :
ISO SGS BV TUV
Place of Origin :
China
MOQ :
10KG
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
1000000Tons per Year
Delivery Time :
3-15 work days
Packaging Details :
Plywood case,pallet,woven bag,or other Seaworthy packed as customed
Product Name :
Alloy Steel Pipe ASTM P22 Pipe Seamless Welded Pipe Beveled Plain End
Standard :
ASTM A335
Material :
Alloy Steel
Prodcut :
Steel Pipe
Type :
Seamless or welded
OD :
1/2"-48”
Thickness :
SCH 5-SCH XXS
End :
BE or PE
Description

ASTM A335 P22 Seamless Pipe Beveled Plain End SCH 5 - SCH XXS Alloy Steel

1. Specification :

Size : 1/8NB TO 24NB IN
Standards : ASTM A 335, ASME SA 335
Type : Seamless
Specialized in : Large Diameter Size
Outer Dimensions : 19.05mm – 114.3mm
Wall Thickness : 2.0mm – 14 mm
Length : max 16000mm
Schedule : Schedule 20 - Schedule XXS (heavier on request) up to 250 mm thk.
Form : Round, Square, Rectangular, Hydraulic Etc.
Length : Single Random, Double Random & Cut Length.
Tubing End : Plain End, Beveled End, Treaded.

2.Chemical Compositions :

C, % Mn, % P, % S, % Si, % Cr, % Mo, %
0.015 max 0.30-0.61 0.025 max 0.025 max 0.50 max 1.90-2.60 0.87-1.13

3.Mechanical Properties :

Tensile Strength, MPa Yield Strength, MPa Elongation, %
415 min 205 min 30 min

4. Heat Treatment Requirements :

P5, P9, P11, and P22
Grade Heat Treatment Type Normalizing Temperature Range F [C] Subcritical Annealing
or Tempering
Temperature Range F
[C]
P5 (b,c) Full or Isothermal Anneal
Normalize and Temper ***** 1250 [675]
Subcritical Anneal (P5c only) ***** 1325 - 1375 [715 - 745]
P9 Full or Isothermal Anneal
Normalize and Temper ***** 1250 [675]
P11 Full or Isothermal Anneal
Normalize and Temper ***** 1200 [650]
P22 Full or Isothermal Anneal
Normalize and Temper ***** 1250 [675]
P91 Normalize and Temper 1900-1975 [1040 - 1080] 1350-1470 [730 - 800]
Quench and Temper 1900-1975 [1040 - 1080] 1350-1470 [730 - 800]

5. Tensile Requirements :

Seamless
P-5 P-9 P-11 P-22 P-91 P91 shall not have a hardness not exceeding 250 HB/265 HV [25HRC].
Tensile Strength, min., psi
ksi 60 60 60 60 85
MPa 415 415 415 415 585
Yield Strength, min., psi
ksi 30 30 30 30 60
MPa 205 205 205 205 415

6. Alloy Steel P22 Pipe Price List

P22 Alloy Steel seamless pipes
US $2500-4100 / Ton (FOB Price)

seamless pipe astm A335 Alloy Steel P22
US $20-1200 / Ton (FOB Price)

Alloy Steel P22 seamless pipe
US $500-2000 / Ton (FOB Price)

ASTM A335 P22 Alloy Steel High Pressure pipe
US $850-2200 / Metric Ton (FOB Price)

sa335 P22 seamless pipe
US $1.5-9 / Kilogram (FOB Price)

P22 Alloy seamless pipe manufacturer
US $850-2200 / Metric Ton (FOB Price)

ASTM A335 Gr.P22 Chrome moly Pipe
US $500-1000 / Ton (FOB Price)

7. Alloy Steel P22 Seamless / High Pressure Pipes Application Industries

Off-Shore Oil Drilling Companies

Power Generation

Petrochemicals

Gas Processing

Specialty Chemicals

Pharmaceuticals

Pharmaceutical Equipment

Chemical Equipment

Sea Water Equipment

Heat Exchangers

Condensers

Pulp and Paper Industry

ASTM A335 P22 Seamless Pipe Beveled Plain End SCH 5 - SCH XXS Alloy Steel
