ASTM B622 UNS N06200 Hastelloy C2000 Seamless Nickel Alloy Pipe And Tube
ASTM B622 UNS N06200 Hastelloy C2000 Seamless Nickel Alloy Pipe And Tube
ASTM B622 UNS N06200 Hastelloy C2000 Seamless Nickel Alloy Pipe And Tube
ASTM B622 UNS N06200 Hastelloy C2000 Seamless Nickel Alloy Pipe And Tube
Specifications
Brand Name :
HT
Model Number :
ASTM B622 UNS N06200 Hastelloy C2000 seamless nickel alloy pipe and tube
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 pcs
Price :
USD 1000/piece
Payment Terms :
L/C,T/T, Western Union
Supply Ability :
1000 pcs per month
Delivery Time :
30-35 work days
Packaging Details :
wooden case, wooden pallet
Product Type :
Pipe Tube
Name :
ASTM B622 UNS N06200 Hastelloy C2000 seamless nickel alloy pipe and tube
Size :
1/2"-60"
Length :
fixed random
Technics :
hot/cold rollded drawn
Material :
Nickel alloy/stainless steel/duplex stainless
Description
ASTM B622 UNS N06200 Hastelloy C2000 seamless nickel alloy pipe and tube
1.Hastelloy C2000 material introduction
This alloy was developed to broaden the application range of one alloy. With the addition of Copper to the Nickel-Chromium-Molybdenum system, Hastelloy C-2000 is resistant to an extensive range of corrosive chemicals, including sulphuric, hydrochloric and hydrofluoric acids. The combination of Molybdenum and Copper provide excellent corrosion resistance to reducing media, while the high Chromium content gives good oxidising resistance.
JIS NW 6200 Hastelloy® Pipes and Tubes Equivalent Indian Standard
STANDARD UNS WNR.
Hastelloy C2000 N06200 2.4675
ASTM B622 Hastelloy C-2000 Seamless Pipe & Tube Chemical Composition
Grade Ni Mo Cr Fe W Co Mn C V P Si
Hastelloy C2000 Remainder 15.0-17.0 14.5-16.5 4.0-7.0 3.0-4.5 2.5 max 1.0 max .01 max .35 max .04 max .08 max
ASME SB626 Hastelloy® C2000 Welded Tubing Mechanical Properties
Grade Tensile Strength Yield Strength Elongation at break
Hastelloy C2000 690 MPa 310 MPa 45%
2.Hastelloy C-22 pipe and tubes specification
Surface Black,bright,rough turned,grinding,centreless Ground etc
Standard GB,AISI,ASTM,DIN,EN,SUS,UNS etc
Diameter 0.5-500mm
Technique Hot Rolled,Cold Rolled,Cold Drawn,Forged
Grade Alloy : Alloy 20/28/31;
Hastelloy: Hastelloy B / B-2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N;
Haynes: Haynes 230/556/188;
Inconel: Inconel 100/600/601/602CA/617/625713/718738/X-750,Carpenter 20;
Incoloy: Incoloy 800/800H/800HT/825/925/926;
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
Monel: Monel 400/K500
Nitronic: Nitronic 40/50/60;
Nimonic: Nimonic 75/80A/90 ;
Nickle: Nickle 200/201;
3.The difference between C276, 22, 59, Hastelloy® C2000 and 686
Alloy (UNS) Ni Cr Mo W Cu Fe Carbon
C276 (N10276) Bal 14.50-16.50 15.00-17.00 3.00-4.50 – 4.00-7.00 0.010max.
22 (N06022) Bal 20.00-22.50 12.50-14.50 2.50-3.50 – 2.00-6.00 0.015max.
59 (N06059) Bal 22.00-24.00 15.00-16.50 – – 1.00 nom. 0.010max.
686 (N06686) Bal 19.00-23.00 15.00-17.00 3.00-4.40 – 1.00 max. 0.010max.
C2000® (N06200) Bal 22.00-24.00 15.00-17.00 – 1.30-1.90 3.00 max. 0.010max.
Pitting Resistance Equivalent
Critical pitting resistance and crevice corrosion properties can be measured using the “pitting resistance equivalent” (PREN or PRE) index.
Alloy PREN INDEX PRE INDEX
686 51 74
59 47 76
C2000® 47 76
22 46 65
C276 45 59

4.Hastelloy C2000 hydrostatic test
ASTM B622 UNS N06200 Hastelloy C2000 Seamless Nickel Alloy Pipe And Tube
