Specifications
Brand Name :
iTruck
Place of Origin :
Hubei, China
MOQ :
1
Price :
$29,000.00 - 41,000/units
Supply Ability :
5 sets per month
Delivery Time :
75 days
Packaging Details :
Nude, covered with film protection
Product name :
Integrated Wrecker Truck Body
Transmission Type :
Manual
Dimensions (L x W x H) (mm) :
Customs made
Condition :
New
WheelBase :
As required
Subframe :
Equipped
Main Winch :
15 - 25 tons, 2 pcs
Underlift :
3 sections, optional 4
Underlift Tow Rating :
28 Ton
Operation :
Both sides manual
Remote Control :
Optional
Warranty :
2 Year
Description
30 TONS TO 50 TONS HEAVY DUTY INTEGRATED WRECKER TOW TRUCK BODY
Product Description

The heavy duty integrated series have different capacities from 20 tons to 50 tons.


The heavy duty integrated wrecker features a 66,000 lb. - 111,000 lb. 2- or 3-stage wrecker boom, corrosion, resistant body and optional 3- or 4-stage underlifts – all designed with strength and performance in mind.


Main Features
1. 15 Tons / 33,200 lbs. - 25 Tons / 55,000 lbs. Planetary Winch, 2 Pcs. Total 30 Tons / 66,600 lbs - 50 Tons / 111,000 lbs.
2. 28 Tons / 62,200 lbs. Underlift Capacity, Tow Rate At Least 56 Tons / 124,000 lbs.
3. Optional Remote Control
4. Sides Tool Boxes
5. Optional Front Legs and Side Pullers

Specs
Heavy Duty Integrated Wrecker Body
No. Item Content Details Details Details
1 Name
30 Tons Wrecker Body 40 Tons Wrecker Body 50 Tons Wrecker Body
2 Winches
2×15 Tons Main Winches 2×20 Tons Main Winches 2×25 Tons Main Winches
3 Under lift Under lift G70 material, 3-4 stage
4 Boom Boom G70 material, 2-3 stage, hexagon
5 Legs Rear Hydraulic rear supporting legs
6 Frame LED Lights Frame, full size

7 Toolbox On Both Sides Carbon steel Q345R, with stainless steel handles
8 Hook-Ups Air and Electrical Hook-Ups 12V or 24V
9 Control Remote Wireless Control Button remote control


Hand Manual Control On Lift and Right Sides, English Indication
10 Hydraulic Parts Hydraulic Pump Double Pump


Hydraulic Hose



Hydraulic Connector



Valves Italy


Cylinders

11 Attachments 5 Sets of Forks 4 sets for axle, 1 set for suspension


U shape tyres holder 1 set


Safety Chains 2 pcs
12 Painting and Indication Electrophoresis Painting Tool Box EP painting, other normal painting


Surface Painting Epoxy Resin


Indication English Indication and Marks


Packaging Boxes and under lift protected for the painting
Specifications
1 Underlift Retracted Lifting Capacity 25000 28000 28000


Retracted Length 1746 1746 1746


Extended Lifting Capacity 7310 7310 7310


Extended Length 3110 3410 3410


Undelift Tilt -10 -10 -10


Towing Capacity 50 56 56
2 Boom Retracted Lifting Capacity (45°) 30 40 50


Extended Lifting Capacity (45°) 8 10 11.5


Max. Lifting Tilt 33 33 33


Max. Lifting Height 7022 7022 7022
3 Main Winches Quantity 2 2 2


Pulling Power 15 20 25


Type Planetary Planetary Planetary


Steel Wire Length 45 45 45


Steel Wire Diameter 18 26 28


40 Tons Heavy Duty 3 Stages Booms Integrated Wrecker Body 40 Tons Heavy Duty 3 Stages Booms Integrated Wrecker Body
