SINOTRUK HOWO 10 TONS water tank water cannon truck with water pump
SINOTRUK HOWO 10 TONS water tank water cannon truck with water pump
SINOTRUK HOWO 10 TONS water tank water cannon truck with water pump
SINOTRUK HOWO 10 TONS water tank water cannon truck with water pump
SINOTRUK HOWO 10 TONS water tank water cannon truck with water pump
SINOTRUK HOWO 10 TONS water tank water cannon truck with water pump
SINOTRUK HOWO 10 TONS water tank water cannon truck with water pump
SINOTRUK HOWO 10 TONS water tank water cannon truck with water pump
Specifications
Brand Name :
HOWO
Certification :
ISO
Place of Origin :
Hubei
MOQ :
1
Price :
$20500-$21000 per unit
Payment Terms :
T/T, L/C
Supply Ability :
50 units per month
Delivery Time :
15-35 days
Packaging Details :
nude with waxing
Product Name :
water tank truck
Volume :
10000 liters
Chassis model :
HOWO, optional DFAC,ISUZU,SHACMAN,FAW
Engine :
160hp YUCHAI engine
Wheelbase :
4200 mm
Function :
spraying water and delivery drinking water
Drive model :
4x2
Tire :
8.25R20
Transmission :
10-speed, manual
Emission standard :
Euro 3
water tank material :
carbon steel or stainless steel
Description

Pictures:

The water tank truck is suitable for all kinds of road washing, trees, green belts, lawn greening, construction of roads, factories and mines, and high-altitude buildings. The watering truck can also be used as a water trasnpotation truck. The most common models are sanitation watering truck, multi-function watering truck and green watering truck.
Our company's products come standard with front spray (duck bill), back flush, rear spray, side spray, and rear-mounted working platform. The platform is equipped with a green water cannon (which can be rotated 360°, and can be adjusted to either a column or a mist shape). , it can be adjusted to flush, heavy rain, moderate rain, light rain, drizzle), equipped with high-quality high-power special sprinkler pump (self-priming and self-draining, can pump water from river or pond to tank), power take-off, miscellaneous material filter screen, fire interface, self-flowing ball valve system, ball valve and filter screen are all national standard products, the main pipeline is thickened, the flange gasket and flange plate are thickened, and the large-diameter ball valve is used. The overall performance is excellent, safe and reliable, high efficiency, large flow, convenient maintenance and so on.

SINOTRUK HOWO 10 TONS water tank water cannon truck with water pump.

Main specification :

Complete Vehicle Parameter
Vehicle HOWO water tank truck
Overall dimensions (mm) 7950 x 2480 x 3200
Water tanker (L) 10000
Gross Vehicle Weight (kg) Appro × 16800
Net weight (kg) Appro × 6800
Loading (kg) Appro × 10000
Wheel base (mm) 4200
Max speed (Km/h) 89
HOWO Truck Chassis Parameter
Cabin One and half row cabin, a sleeper, power steering, air conditioner,manual window, 3 passengers,left hand drive.
Drive form 4×2
Engine

Brand: YUCHAI

Model: YC4E160 33

Engine power: 160hp

Fuel type: diesel

Displacement: 4.257L

Emission standard : Euro 3
Transmission 10 forward,2 reverse, manual operated
Tire model 8.25R20
No.of tires 6+1pcs
Oil tank 220L
Superstructure Parameter
Characteristics

1) Carbon steel material water tank, thickness 5mm.

2) With water pump.

3) With rear working platform.

4) With suction pipe.

5) With fire connector.

6) With gravity valve.
Special performance

1) Front and rear spraying water.

2) Left and right side spraying water.

3) Platform has a sprinkler, spraying water.

4) Water column can be adjusted into mist

5) Width of spraying water : ≥14m.

6) Distance of spraying water : ≥28m.

7) Vertical suction 6-8 m.
Applicable scope

1. for a variety of road cleaning

2. City green sanitation

3. Trees, green belt and lawn watering

4. High altitude building rinse
