4X2 left hand drive ISUZU FTR truck water tank 10000-15000 liter water sprinkler
4X2 left hand drive ISUZU FTR truck water tank 10000-15000 liter water sprinkler
4X2 left hand drive ISUZU FTR truck water tank 10000-15000 liter water sprinkler
4X2 left hand drive ISUZU FTR truck water tank 10000-15000 liter water sprinkler
4X2 left hand drive ISUZU FTR truck water tank 10000-15000 liter water sprinkler
4X2 left hand drive ISUZU FTR truck water tank 10000-15000 liter water sprinkler
4X2 left hand drive ISUZU FTR truck water tank 10000-15000 liter water sprinkler
4X2 left hand drive ISUZU FTR truck water tank 10000-15000 liter water sprinkler
Specifications
Brand Name :
ISUZU
Model Number :
FTR
Certification :
ISO
Place of Origin :
Hubei
MOQ :
1
Price :
$38100-$50000 per unit
Payment Terms :
T/T, L/C
Supply Ability :
50 units per month
Delivery Time :
15-35 days
Packaging Details :
nude with waxing
Product Name :
water tank truck
Volume :
10000-15000 liters
Chassis model :
ISUZU, optional DFAC,HOWO,SHACMAN,FAW
Engine :
205HP-240HP
Wheelbase :
4500-5550 mm
Function :
spraying water and delivery drinking water
Drive model :
4x2
Tire :
295/80R22.5
Transmission :
8-speed, manual
Emission standard :
Euro 6
water tank material :
carbon steel or stainless steel
Description

Pictures:

The water tank truck is suitable for all kinds of road washing, trees, green belts, lawn greening, construction of roads, factories and mines, and high-altitude buildings. The watering truck can also be used as a water trasnpotation truck. The most common models are sanitation watering truck, multi-function watering truck and green watering truck.
Our company's products come standard with front spray (duck bill), back flush, rear spray, side spray, and rear-mounted working platform. The platform is equipped with a green water cannon (which can be rotated 360°, and can be adjusted to either a column or a mist shape). , it can be adjusted to flush, heavy rain, moderate rain, light rain, drizzle), equipped with high-quality high-power special sprinkler pump (self-priming and self-draining, can pump water from river or pond to tank), power take-off, miscellaneous material filter screen, fire interface, self-flowing ball valve system, ball valve and filter screen are all national standard products, the main pipeline is thickened, the flange gasket and flange plate are thickened, and the large-diameter ball valve is used. The overall performance is excellent, safe and reliable, high efficiency, large flow, convenient maintenance and so on.

4X2 left hand drive ISUZU FTR truck water tank 10000-15000 liter water sprinkler.

Main specification :

Complete Vehicle Parameter
Vehicle ISUZU water tank truck
Overall dimensions (mm) 8200 x 2500 x 3200
Water tanker (L) 12000
Gross Vehicle Weight (kg) Appro × 18500
Net weight (kg) Appro × 6500
Loading (kg) Appro × 12000
Wheel base (mm) 4500
Max speed (Km/h) 95
ISUZU Truck Chassis Parameter
Cabin FTR cabin, a sleeper, power steering, electric window, air conditioner, 3 passengers,left hand drive.
Drive form 4×2
Engine

Brand: ISUZU

Model: 4HK1-TC60

Engine power: 205hp

Fuel type: diesel

Displacement: 5.193L

Emission standard : Euro 6
Transmission 8 forward,1 reverse, manual operated
Tire model 295/80R22.5
No.of tires 6+1pcs
Superstructure Parameter
Standard configuration

1) Carbon steel material water tank, thickness 5mm.

2) With water pump.

3) With rear working platform.

4) With suction pipe.

5) With fire connector.

6) With gravity valve.

7) With rear arrow light.
Special performance

1) Front and rear spraying water.

2) Left and right side spraying water.

3) Platform has a sprinkler, spraying water.

4) Water column can be adjusted into mist.

5) Width of spraying water : ≥14m.

6) Distance of spraying water : ≥28m.

7) Vertical suction 6-8 m.
Applicable scope

1. for a variety of road cleaning

2. City green sanitation

3. Trees, green belt and lawn watering

4. High altitude building rinse

4X2 left hand drive ISUZU FTR truck water tank 10000-15000 liter water sprinkler
