Shopping Mall 46 Inch FHD LCD Digital Signage Display
Shopping Mall 46 Inch FHD LCD Digital Signage Display
Shopping Mall 46 Inch FHD LCD Digital Signage Display
Shopping Mall 46 Inch FHD LCD Digital Signage Display
Shopping Mall 46 Inch FHD LCD Digital Signage Display
Shopping Mall 46 Inch FHD LCD Digital Signage Display
Shopping Mall 46 Inch FHD LCD Digital Signage Display
Shopping Mall 46 Inch FHD LCD Digital Signage Display
Specifications
Brand Name :
HUIGUAN
Certification :
CE, FCC, ROHS, CCC, ISO9001, ISO4001
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
negotiation
Delivery Time :
5-8 work days
Packaging Details :
negotiation
Product name :
55 Inch Wall Mount 4K Advertising Lcd Screen Hd Digital Video Wall
Panel Size :
55" LCD Screen
Input Voltage :
AC100V~240V 50/60Hz
Backlit :
LED
Pixel Pitch :
0.63(H)*0.63 (V)mm
Response Time :
8ms
Viewing Angle :
178°/178°
Power Supply :
AC100V~240V 50/60Hz
IR Remote :
optional
After-sales Service Provided: :
Video technical support, Free spare parts, Field installation, c
Description

Shopping Mall 46 Inch FHD LCD Digital Signage Display

Product Description

Description of LCD Video Wall

♦ Ultra narrow design

♦ Built-in 3D nose reduction ,Its operating noise level is under 25 dB, which is quieter than a typical recording studio (30 dB)

♦ LED backlight technology provides high uniformity in brightness to ensure a clear picture

♦ Easy Management with LAN ( DP)Daisy Chain

♦ 4K input supported

♦ Multi touch screen supported

Advantages of LCD Video Wall

♦ Ultra Narrow Bezels: A thin-profile design and a screen-to-screen bezel width of as little as 1.7mm, 1.8mm ,3.5mm and 5.5mm bezel.

♦ Superior brightness : High contrast ratios and brightness of up to 7000 nits.

♦ Wide viewing angle: DID LCD panel makes the viewing angle up to 178°.

♦ Active backlighting system : Active backlighting technology, which prompts the LED backlight to adjust automatically to content displayed on the screen.

♦ 24/7 reliable: 24/7/365 continuous operation.

♦ Ultathin and lightweighted: The ultra thin and lightweighted design makes it easy to transport and install.

♦ Economic al and practical: High performance and high quality make it cost less.

Product Description

Model No. HG-3003
Panel size 55″ TFT-LCD
Display area(mm)/mode 1209.6mm(H) x 680.4mm(V) 16:9
Maximum resolution 1920*1080
Display color 1.073G(10bits/color)
Pixel Pitch(mm) 0.21mm(H) x 0.63mm(V) (mm)
Brightness (nits) 1500cd/m*m 1500 nits
Contrast 4000:1
Visual angle 178°/178°
Response time 6.5ms
Life(hrs) >60,000(hrs)
Touch Panel
Specification Infrared touch
Positioning
accuracy		 ±2mms
Transmittance 92%
Hardness 7H
Click manner double point/mult-point(optional)
Response time 10ms
Output Resolution 4096X4096
Life time Single point of more
than 600 million times
Input and output
VGA input 2
CVBS input 2
YPbPr input 1
TV 1
HD 4
USB2.0 6
LAN 1
PC Audio 1
Audio(L/R) input 1
Audio(L/R) output 1
Thermal printer 1
Speaker 2×10W(8 ohm)
Video
Color system PAL/NTSC/SECAM
Remote controller Special
OSD display( screen menu display)
Menu language Chinese/English
Computer
Main chipset Intel H61
CPU Intel I3-3220 3.1GHz
System bus frequency 800/1066/1333 MHz
Graphics card Integrated
Audio card Integrated AC97
Network card Integrated 10/100/1000M adaptive
Memory DDRIII 2G (max to 4G)
Hard Disk 32G SATA (max to 1 TB)
WIFI Yes
Bluetooth Optional
Operation system Windows/Linux
Power
Power supply AC100~240V 50 /60 HZ
Maximum power consumption 3600W
Standby power consumption <5W
Temperature
Working temperature 0℃~50℃
Storage temperature -20℃~60℃
Working humidity 85%
Storage humidity 85%
Waterproof grade Outdoor IP34
Temperature control Air cooling(Fans)
Appearance
Panel color/appearance White, black, customized
Panel material Metal case SPCC
Installation flood-standing/wall mounted
Pricing(EXW Shenzhen)
Detailed functions
Video format MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI
Audio format Wave/MP3/WMA/AAC
Image format JPEG/BMP/TIFF/PNG/GIF
Image resolution 480P/720P/1080P
Split screen display Editable
Running subtitle location, word size, color and backlight are editable
