Interactive Touch Screen Digital Signage

Product Description
Education Kiosk
To match the competitive environment of schools, colleges, and universities; Education Kiosk Application or better known as Student Information Touch Screen Kiosk has been designed that paves the way for the easiest access to education-related features such as availability of the internet, registration process, review process and more. This School Management kiosk is extremely helpful in managing heavy traffic during admission and events process and it is equally helpful as touch screen kiosk for college.
By using Education Kiosk Application, schools have improved their efficiency by providing automated solutions for many different categories such as admission process, fees, timetable, library management and many more and for these many features, this kiosk is also known as time table management kiosk. Attendance management is also a key feature of this kiosk. Along with managing administrative tasks, this kiosk is equally useful for students through which they review the books.
• Customized Product
• Students’ Personal Information
• Class Schedule Information and School Notices
• Personalized course schedules, academic records and billing information for students
• Grades and Degree Evaluations,
• Fee Management System
• Time table Management System
• Communicate academic calendar and course schedule information with students
• Emergency or Personalized Notice to Students and check-in for their appointments Request
• School/College Personalized General Instructions
• Saves time – shorter lines at check-in locations.
• Provides an easy way to completely free repeated administrative Tasks
• Easy to keep student contact information updated
• Updates parents about their wards’ activities
• Send notifications and alerts to parents for meetings
• University administration terminals, offering students a range of services.
• Education terminals, allowing younger children to become more familiar with technology.
• Public Internet access kiosks, making the Internet available to everyone.
• Library check-in and check-out kiosks, facilitating borrowing of books for users
• Test and examination terminals, where students can sit exams both in school and remotely, and receive their marks instantly.

Specification

Single Touch

• 15”,17”,19”,22” or higher

Multi Touch

• 22” or higher

Touch screen

• High transparency, high precision and durability
• Vandal Proof
• Projected Capacitive Touch
• Anti-rust, anti-acid, anti-dust
• Saw touch and IR touch for option
• Capacitive,225 Million Touch
• Accuracy 1% of true precision
• 16K x16K touch screen resolution Bare
• Finger Activation, not affected by surface contaminants like dust, grease, moisture, liquids etc.
• Specification

  Product Details	Value
  Screen brand:	LG/SAMSUNG/AUO
  OS	WindowsXP,Windows7,Windows8, etc. / All windows/Linux/Android
  Panel	A+ Grade new panel
  HDD	500GB/3.5"/7200rmp
  Type	Touch screen LCD payment terminal Kiosk
  CPU	Intel Core 2 Duo J1800 2.41G / Rk3288,CortexA-17Quad Core, 1.8GHz
  Speaker	5Wx2
  Material	SPCC
  Surface	Power Coating
  Disk	64G(SDD) / 8G,32G,16G,64G
  Mouting Options	Floor stand, wall mount and counter Top
  Memory	DDR3 2G / 4G
  Response Time	10ms
  Screen Size	32'' ( optional from 8inch to 65inch)
  Color	Black,white,Red or customzied
  Resolution	1920x1080
  Aspect Ratio	16:09
  Brightness	400cd/m2
  Contrast Ratio	1100:01:00
  Viewing Angle	H178° V178°
  Display Colors	16.7M
  Refresh Rate	60Hz
  Touch panel Durability	Scratch-free, more than 60,000,000 touches without failure
  Panel Life	30000
  Touch Panel Thickness	3mm
  Printer	58mm Thermal Printer with Auto Cutter
  Scanner	2D, Area Imaging Scanner
  CardReader	Customized
  Voltage	AC90V-240V,50/60HZ
  Power Consumption	100W
  Application	Indoor
  Working Temperature	0-40° C
  Storage Temperature	20-60° C
  Working Humidity	20%-80%
  Storage Humidity	10%-90%
  Frequency	50Hz to 60Hz
  Output over current protection	110~130%
  PC Power Supply	Great Wall
  Industrial Board	Seavo/ Gigabyte/Advantech AIMB 562
  Warrenty	1 Year
  Auto-Cut	Included
  Main Components	Bill acceptor,thermal printer,card Reader
  Accessories	Wire-lan port, USB ports, speakers, fans, cables, screws, adapter, User Manual etc.
  Other Pripheral Devices	Coin Acceptor/UPS/WIFI/Webcam/Note Dispenser
  Camera	High quality digital camera
  Functions	Update remotely /Split Screens/ Log Management/ Weather Function / Time and Date /Live Broadcast /Cloud Streaming
  Integeration	Integerated TV detector / Integrated HDMI 1.4 transmitter with HDCP support

  Trade Information
  Price Setting	Set one FOB price
  FOB	USD
  FOB Price	$ 500 - 3000 / Pieces
  MOQ	1 Pieces
  Payment Options	LC/TT

  Logistics Information
  Processing Time	7-20 WOKING DAYS
  Port	Chennai
  Supply Ability	500 Pieces/ Month
  Packaging Details	Glass Surface Coated+ Bubble Foam + Pearl Cotton(EPE) + Cardboard Case + Carton Box + Waterproof Wooden Case(Plywood Standard Export Packing with Cartons and Foam inside for protecting KIOSK & BIG MAGIC MIROR)
