Thermal Imaging PTZ Camera Long Range Night Vision Outdoor Temperature Detection Camera

• Integrated infrared thermal camera, visible light camera,PTZ control system, day and night omnidirectional video surveillance.

• Using thermometer, no light source limitation, clear imaging.

• Day and night 2.0 megapixel star level low illuminance color camera for detail observation.

• The zoom camera and the thermal imaging camera are managed and set by the same IE or client.

• Support standard ONVIF protocol, back-end compatible with market standard onvif recorder recording and control.

• 3D positioning function, which can realize frame selection amplification and click centering function, easy operation and improve equipment usability.

• The universal variable speed pan/tilt realizes all-round blind angle monitoring and achieves high-precision positioning.

• The first independent defogging and defrosting module . Solves the fogging of the camera lens caused by the temperature difference in the outdoor environment.

• The PTZ comes standard with an original voltage regulator module that filters the instantaneous unstable current of the vehicle and keeps the gimbal stable.

Thermal Camera

♦ Excellent thermal image effect 384*288 resolution.

♦ AGC automatic gain adjustment, 3D noise reduction, DDE image detail enhancement.

♦ Black hot / white hot / iron red / rainbow and other fake colors (14 kinds of pseudo color adjustable).

♦ Accurate temperature measurement, the highest temperature cross positioning.

♦ Support 1 line temperature measurement 10 box temperature measurement and 10 point temperature measurement.

♦ Temperature range: -40 ℃ -550℃ temperature measurement accuracy: ± 2 ℃ (or ± 2% of the range).

♦ Abnormal temperature alarm, support 2 hardware alarm input, 2 alarm output.

♦ Support standard ONVIF protocol and support SDK.

Zoom camera

♦ Resolution 2 megapixel HD, 1920 * 1080P.

♦ 20x/30x optical zoom optional.

♦ Standard ONVIF protocol. Support H.264 & H.265.

PTZ

♦ 360° continuous rotation in the horizontal direction, vertical 60°~-90°, keying speed level 0.1°-110°/s vertical 0.1°-50°/s.

♦ 256 preset positions with preset point video freeze function.

♦ 6 cruise scans, each of which can add 32 preset points.

♦ 4 pattern scans, each path is recorded for more than 10 minutes.

♦ The camera compartment uses high-quality heating parts to make the entire warehouse body work together to form an effective anti-fog and defogging pattern.

♦ The pan/tilt adopts the integrated structure of the upper and lower spindles, so that the camera head and infrared bin of the gimbal will not be bumped and misplaced.

♦ The PTZ is equipped with an original voltage regulator module to filter the instantaneous unstable current of the vehicle and keep the PTZ stable.

♦ Support infrared fill light greater than 50 meters, support wiper.

Technical data
