Specifications
Brand Name :
Vegoo
Model Number :
VG-HD 1.923
Certification :
CE/ROHS/FCC/
Place of Origin :
China
MOQ :
1Sq.m
Payment Terms :
Western Union, T/T
Supply Ability :
1500Sqm/months
Delivery Time :
15 working days
Packaging Details :
Plywood case / Flight case / Carton box
product name :
P1.923 Indoor Full color LED Display
Pixel Pitch :
1.923mm
Density :
270,410 pixel/m2
Moduel Size(L×W)mm :
200mm×150mm
Module Resolution :
104×78
Driving Method :
1/26 Scan
Driving IC :
MBI5153
Brightness :
600cd/㎡
Description

1R1G1B / SMD1515 P1.923 Indoor Full color LED Display HD LED Display

P1.923 Indoor Full color LED Display Specification

Product Name Specification
Pixel Pitch 1.923mm
Pixel Configuration 1R1G1B/SMD1515 Black lamp
Density 270,410 pixel/m2
Moduel Size(L×W)mm 200mm×150mm
Cabinet Size(L×W×H)mm 400mm×300mm×65mm
Module Resolution 104×78
Cabinet Resolution 208×156
Driving Method 1/26 Scan
Driving IC MBI5153
Brightness 600CD/㎡
Contrast 1000:1
Brightness Adjustment Auto and Manual
Power Consumption Max Power:<1000W
Average power: <450W
Module Weight 0.15kg
Color Temperature 9500K—11500K
Horizontal Viewing Angle 140º
Vertical Viewing Angle 140º
Signal Processing 10 or 14bit
Grey Processing 1024×1024×1024
16834×16834×16834
Control Distance cable100m,Multimode500m,Single mode 2km
Frame Frequency 65 Hz
Refresh Rate >3840Hz
Control Mode Synchronous/Asynchronous
The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
Users can choose the recommended curve or adjust it based on actual situation
MTBF >50000 hours
Life Span 100,000 Hours
Operating Temperature Working : -20 - 65 ℃
Storage : -40 - 85 ℃
Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
Power Supply AC 85-264V
Protection Level IP 41

IP41 P1.923mm Commercial Advertising HD LED Display MBI5153 600CD/㎡
