Specifications
Brand Name :
VEGOO
Model Number :
VG-P3
Certification :
CE ROHS FCC
Place of Origin :
CHINA
MOQ :
1 SQM
Price :
USD500-900 per m2
Payment Terms :
T/T
Supply Ability :
3000 sqm per month
Delivery Time :
8-15 working day
Packaging Details :
0.2025 CBM
Tube chip color :
Full Color
Cabinet size :
400 mm x 300 mm
Usage :
indoor
Screen dimension :
Customized
Warranty :
3 Years
Brightness :
800cd/sqm
Refresh rate :
1920Hz-3840Hz
Life span :
100000hours
Scan mode :
1/16scan
Pixels :
1.25mm
Description
P3 Indoor Full color LED Display Specification
NO: Product Name Specification
1 Pixel Pitch 1.25mm
2 Pixel Configuration 1R1G1B/SMD2121 Black lamp
3 Density 640000pixel/m2
4 Moduel Size(L×W)mm 200mm×112.5mm
5 Cabinet Size(L×W×H)mm 600mm×337.5×50mm
6 Module Resolution 160×90
7 Cabinet Resolution 480×270
8 Driving Method 1/32 Scan
9 Driving IC MBI5124 or ICN 2038S
10 Brightness 800cd/㎡
11 Contrast 1000:1
12 Brightness Adjustment Auto and Manual
13 Power Consumption Max Power:＜800W
14 Average power: ＜200W
15 Module Weight 0.25kg
16 Color Temperature 9500K—11500K
17 Horizontal Viewing Angle 140º
18 Vertical Viewing Angle 140º
19 Signal Processing 10 or 14bit
20 Grey Processing 1024×1024×1024
16834×16834×16834
21 Control Distance cable100m,Multimode500m,Single mode 2km
22 Frame Frequency 65 Hz
23 Refresh Rate >1920Hz
24 Control Mode Synchronous/Asynchronous
25 The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
26 Users can choose the recommended curve or adjust it based on actual situation
27 MTBF >50000 hours
28 Life Span 100,000 Hours
29 Operating Temperature Working : -20 - 65 ℃
30 Storage : -40 - 85 ℃
31 Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
32 Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
33 Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
34 Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
35 Power Supply AC 110-220V
36 Protection dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)
