About Us:
We are one of the professional led display manufacturers in China and we have our own researching
and developping department for customized led display and solutions . To cooperatted with us , you
will save more money and more precious time.

Our factory is located in Guangming New district , Shenzhen , China.

With Excellent Location, we can deliver your order to Shenzhen international Airport within 30 minutes and to Yantian port (one of the bigest port in the world) within 40 minutes .

Applications:
Our products widely used in various public places such as commercial plaze , Stations ,Airport ,Stadiums,
Transport Facilities,Museum , Sience Museum , Theme park, Theater, Stage etc......

Our products range covered all Led modules & displays, From Pixel Pitch P0.9 to P10 SMD indoor and from P3 to P10 SMD outdoor displays . More is that we have our own D&P dpt for providing you many creative led display solutions.

NO: Product Name Specification
1 Pixel Pitch 3.0mm
2 Pixel Configuration 1R1G1B/SMD2121 Black lamp
3 Density 111111 pixel/m2
4 Moduel Size(L×W)mm 48mm×48mm
5 Cabinet Size customized
6 Module Resolution 16 X 16
7 Cabinet Resolution according to actual size
8 Driving Method 1/16 Scan
9 Driving IC MBI5153
10 Brightness 600CD/㎡
11 Contrast 1000:01:00
12 Brightness Adjustment Auto and Manual
13 Power Consumption Max Power:＜800W
14 Average power: ＜300W
15 Module Weight 0.05kg
16 Color Temperature 6000K—9000K
17 Horizontal Viewing Angle 120º
18 Vertical Viewing Angle 120º
19 Signal Processing 10 or 14bit
20 Grey Processing 1024×1024×1024
16834×16834×16834
21 Control Distance cable100m,Multimode500m,Single mode 2km
22 Frame Frequency 65 Hz
23 Refresh Rate >3840Hz
24 Control Mode Synchronous/Asynchronous
25 The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
26 Users can choose the recommended curve or adjust it based on actual situation
27 MTBF >50000 hours
28 Life Span 100,000 Hours
29 Operating Temperature Working : -20 - 65 ℃
30 Storage : -40 - 85 ℃
31 Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
32 Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
33 Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
34 Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
35 Power Supply AC 110-220V
36 Protection IP 41
