Specifications
Brand Name :
Geomax
Model Number :
GM100-330
Certification :
CE
Place of Origin :
ANHUI CHINA
MOQ :
2500 ㎡
Price :
Negotiation
Payment Terms :
T/T, L/C, D/A, D/P, Western Union
Supply Ability :
3000㎡ per day
Delivery Time :
10-20 days
Packaging Details :
Folded strips are wrapped by film and layed on pallets or as requested
Material :
HDPE Plastic
GeoMax Standard :
ASTM
Cell Height :
100mm
Geomax Model :
GM100-330
Color :
Black; Green; Yellow
Welding Space :
330mm
Cell Thickness :
1.5mm
Geocell Surface :
Textured&Perforated
Description

Black HDPE Geocell 100mm Height 330mm Welding Space For Parking Lots Light Vehicles Light Industrial​

Black HDPE Geocell 100mm Height 330mm Welding Space For Parking Lots Light Vehicles Light Industrial

GeoMax® Geocell Product Introduction

GeoMax® is a leading force in the geotechnical industry, drawing on over two decades of expertise in designing and manufacturing advanced cellular confinement systems. Our geocell products are built for exceptional adaptability and performance, supported by more than 100 patented innovations. These advancements enable us to consistently provide reliable solutions that address even the most complex project requirements.

Quality is our top priority at every stage of production. Each GeoMax® geocell system is manufactured in full compliance with ISO and CE standards, ensuring adherence to global quality regulations. These stringent certifications guarantee superior performance and safety across a wide range of engineering and environmental applications.

SPECIFICATIONS

Index Properties Test Method Units Values
Material - - 100% Virgin HDPE
Carbon Black content ASTM D 1603 % ≥1.5
Density ASTM D 1603 g/cm3 0.935-0.965
Sheet Thickness ± 3% ASTM D 5199 mm 1.5
Seam Peel Strength USACE GL-86-19 KN/m ≥14.2
Tensile strength at Yield ASTM D 1603 KN/m ≥22
Environmental stress crack resistance ASTM D 1603 hrs ≥5000
OIT oxidation induction time ASTM D 1603 min ≥150
Type GM330 GM356 GM400 GM432 GM445 GM500 GM660 GM712
Welding Distance(mm) ± 3% 330 356 400 432 445 500 660 712
Cell Depth(mm) ± 3% 50,75,100,150,200,250
Dimensions
Expanded Cell Size (width×length) (mm) ± 3% 250 x 210 260 x 225 290 x 260 320 x 275 315 x 300 360 x 300 470 x 450 510 x 475
Expanded Cell numbers(width×length) 10 x 34 9 x 34 8 x 34 8 x 34 8 x 34 7 x 34 5 x 34 5 x 34
Expanded Section size (width×length) (m) ± 3% 2.50 x 7.14 2.34 x 7.65 2.32 x 8.84 2.56 x 9.35 2.52 x 10.2 2.52 x 11.22 2.35 x 15.3 2.55 x 16.15
Expanded Section Area (m2) ± 5% 17.85 17.9 20.5 23.94 25.7 28.74 35.95 41.18

APPLICATION

Black HDPE Geocell 100mm Height 330mm Welding Space For Parking Lots Light Vehicles Light Industrial

SOIL REINFORCEMETN

Geomax®(Hdpe Geocell) is the solution to soil stabilization or soil reinforcement. It can increase the bearing capacity of the pavement and avoid cracking of the pavement.

Black HDPE Geocell 100mm Height 330mm Welding Space For Parking Lots Light Vehicles Light Industrial

SLOPE PROTECTION

Geomax®(Hdpe Geocell) is the obvious choice for slope protection or erosion control. It has both good drainage effect and slope protection.

Black HDPE Geocell 100mm Height 330mm Welding Space For Parking Lots Light Vehicles Light Industrial

CHANNEL PROTECTION

Geomax®(Hdpe Geocell) delivers stability and protection of channels
exposed to erosive conditions ranging from low to high flows, either intermittent or continuous.

Black HDPE Geocell 100mm Height 330mm Welding Space For Parking Lots Light Vehicles Light Industrial

RETAINING WALLS

Geomax®(Hdpe Geocell) offers highly permeable and acts as a great number of planting pots, allowing rainwater to infiltrate, minimizing runoff.

PRODUCTION LINE

Black HDPE Geocell 100mm Height 330mm Welding Space For Parking Lots Light Vehicles Light Industrial

INVENTION AND TESTING

Black HDPE Geocell 100mm Height 330mm Welding Space For Parking Lots Light Vehicles Light Industrial

PRODUCT AREA

Black HDPE Geocell 100mm Height 330mm Welding Space For Parking Lots Light Vehicles Light Industrial

CERTIFICATES

Black HDPE Geocell 100mm Height 330mm Welding Space For Parking Lots Light Vehicles Light Industrial

FAQ:

Q: What material is Geocell made from?
A:
Our Geocell structures are manufactured from high-density polyethylene (HDPE), providing strength comparable to concrete. The panels are ultrasonically welded at precise intervals to ensure maximum durability. Additionally, they feature perforations that facilitate natural drainage, making them ideal for commercial applications.

Q: What if my project’s dimensions don’t match the standard Geocell panels?
A:
We offer custom-designed Geocell foundation grids tailored to your project’s specific requirements. The flexible panels can be adjusted to accommodate obstacles such as drainage pipes, trees, and other structures—something rigid materials like concrete or steel cannot easily adapt to.

Q: Has GeoMax Geocell undergone testing? Can I access product specifications?
A:
Yes! Our team can provide details on product testing and specifications. We also offer a free commercial evaluation to assess your project and recommend the best solution. You can schedule a consultation, and we’ll respond within a few hours.

Q: Where is GeoMax Geocell manufactured?
A:
GeoMax Geocell is produced in Anhui, China, in state-of-the-art facilities that adhere to strict quality control protocols, ensuring high-performance and reliable products.

Q: Can you provide customized Geocell sizes?
A:
Yes, we can manufacture Geocell in custom sizes to meet the specific requirements of your project.

Q: What standards does GeoMax Geocell comply with?
A:
Our products meet ASTM and GB standards, and we can also accommodate custom specifications based on your project needs.

Q: What are the primary applications of Geocell?
A:
Geocell is widely used for soil stabilization, erosion control, load-bearing support, and slope reinforcement. It is ideal for projects such as roads, railways, retaining walls, green roofs, and landscaping applications.
