Close roop high speed injection molding machine 415 v 50 hz 3 phase 4 line
Close roop high speed injection molding machine 415 v 50 hz 3 phase 4 line
Close roop high speed injection molding machine 415 v 50 hz 3 phase 4 line
Close roop high speed injection molding machine 415 v 50 hz 3 phase 4 line
Specifications
Brand Name :
VAINO
Model Number :
K3-260
Certification :
CE/ISO9001:2000
Place of Origin :
Ningbo,China
MOQ :
1SET
Delivery Time :
15-25 working days after confirm order and received deposit
Packaging Details :
Wooden pellet Wooden case(optional)
Description

Close roop high speed injection molding machine 415 v 50 hz 3 phase 4 line

Description

This protects system components particularly pipe work, from both potentially destructive forces. An additional benefit is the additional energy that can be store while the pump is subject to low demand. These are often placed close to the demand to help over come restrictions and drag from long pipe work runs. An accumulator can maintain the pressure in a system for periods when these are slight leaks without the pump being cycled on an off constantly. when the temperature changes cause pressure excursions the accumulator helps absorb them.

These series machines take the accumulator to help inject, which having high cost performance improve the speed ,quicken the machine circle time, higher the efficiency, and especially suitable for the ultrathin, precious and complicated products.

Specifications

SPECIFICATION
MODEL
Description UNIT K3-260
INJECTION UNIT
Shot volume Cm³ 540 653 778
Shot weight(ps) g 497 601 715
Shot weight(ps) Oz 17.5 21.2 25.2
Screw diameter mm 50 55 60
Injection pressure Mpa 215 177 149
Injection rate g/sec 155 188 223
ScrewL/D ratio 24.2 22 20
Screw stroke mm 275
Screw speed(stepless) Rpm 0～165
Nozzle contact force ton 11
Clamping force ton 260
Opening stroke mm 540
Platen size mmxmm 850X850
Space between tie bars mmxmm 580X580
Max.daylight mm 1140
Mold thickness(min.-max.) mm 200-600
Hydraulic ejection stroke mm 170
Hydraulic ejection force ton 7.1
Ejector pin Unit 9
POWER UNIT
Hydraulic system pressure Mpa 16
Pump motor Kw 22
Heating capacity Kw 17
Number of temp control zones Unit 5
Oil tank capacity L 450
Machine dimensions mxmxm 6.1X1.5X2.2
Machine weight ton 9

ADDITIONAL FUCTION

Voltage

415v 50hz 3phase 4line

Hopper with lid material

SS(stainless)

Alarm system

Light shining with sound

Heating elements

SSR

Heating band quality

Infrared

Condenser

One middle bigger

Core pull function

3 hydraulic+3pheumatic

Machine program

Keba program with 3hydraulic ,3 pheumatic core pull changable

Injection cylinder

2

Servo system

Drive-Huichuan

Motor-Saisi-China

Gear pump-Sumitomo-Japan

Pressure sensor-KAVLICO

Center lubrication system and Manual

Both

Lubrication pipe

Plastc pipe with spring protection

Lubrication distribute

Auto jam detector distribute

Machine bush elements

Copper

Loading and un-loading care

For machine lifting purpose, properly positioned and

clearly marked ‘hooks’ to be provided.
