0.4mm thin wall thickness PP automatic blow moulding machine / blow mold machine
0.4mm thin wall thickness PP automatic blow moulding machine / blow mold machine
Specifications
Brand Name :
VAINO
Model Number :
K2-220s
Certification :
CE/ISO9001:2008
Place of Origin :
Ningbo,China
MOQ :
1SET
Delivery Time :
15-25 working days after confirm order and received deposit
Packaging Details :
Wooden pellet Wooden case(optional)
SHOT VOLUME :
381,470,569
SHOT WEIGHT :
347,429,520G
HYDRAULIC EJECTION STROKE :
150mm
HYDRAULIC EJECTION FORCE :
67kn
MACHINE WEIGHT :
6800KG
MACHINE DIMENSIONS :
5.4X1.3X2.1
Description

0.4mm thin wall thickness PP automatic blow moulding machine / blow mold machine

Detailed Product Description

HIGH-SPEED INJECTION MOLDING MACHINE

It also helps protect the system from fluid hammer.

This protects system components particularly pipe work, from both potentially destructive forces. An additional benefit is the additional energy that can be store while the pump is subject to low demand. These are often placed close to the demand to help over come restrictions and drag from long pipe work runs. An accumulator can maintain the pressure in a system for periods when these are slight leaks without the pump being cycled on an off constantly. when the temperature changes cause pressure excursions the accumulator helps absorb them.

These series machines take the accumulator to help inject, which having high cost performance improve the speed ,quicken the machine circle time, higher the efficiency, and especially suitable for the ultrathin, precious and complicated products.

SPECIFICATIONS

SPECIFICATIONS
DESCRIPTION UNIT K2-220s
INJECTION A B C
SHOT VOLUME CM3 381 470 569
SHOT WEIGHT G 347 429 520
(PS) OZ 12.1 15.0 18.1
SCREW DIAMETER MM 45 50 55
INJECTION PRESSURE MPA 217 176 145
SCREW L:D RATIO 22:1 20:1 18:1
SCREW STROKE MM 240
SCREW SPEED (STEPLESS) R/MIN 0~200
CLAMPING UNIT
CLAMPING FORCE KN 2200
OPENING STROKE MM 480
PLATEN SIZE MM*MM 745*745
SPACE BETWEEN TIE BARS MM*MM 510*510
MOLD THICKNESS (MIN-MAX) MM 200~560
MAX.DAYLIGHT MM 1040
HYDRAULIC EJECTION STROKE MM 150
HYDRAULIC EJECTION FORCE KN 67
POWER UNIT
HYDRAULIC SYSTEM PRESSURE MPA 17.5
PUMP MOTOR(V/S) KW 18.5/28.3
HEATING CAPACITY KW 13.1
NUMBER OF TEMP CONTROL ZONES 4+(NOZZLE )
GENERAL
DRY-CYCLE TIME SEC 4.5
OIL TANK CAPACITY L 310
MACHINE DIMENSIONS MXMXM 5.4*1.3*2.1
MACHINE WEIGHT KG 6800

0.4mm thin wall thickness PP automatic blow moulding machine / blow mold machine

0.4mm thin wall thickness PP automatic blow moulding machine / blow mold machine
