0.5mm thickness PP cup Thin Wall Injection Molding Machine Servo System
0.5mm thickness PP cup Thin Wall Injection Molding Machine Servo System
0.5mm thickness PP cup Thin Wall Injection Molding Machine Servo System
0.5mm thickness PP cup Thin Wall Injection Molding Machine Servo System
Specifications
Brand Name :
VAINO
Model Number :
K2-170s
Certification :
CE/ISO9001:2008
Place of Origin :
Ningbo,China
MOQ :
1SET
Delivery Time :
15-25 working days after confirm order and received deposit
Packaging Details :
Wooden pellet Wooden case(optional)
SHOT VOLUME :
227,318,392
SHOT WEIGHT :
260,298,368G
HYDRAULIC EJECTION STROKE :
140 mm
HYDRAULIC EJECTION FORCE :
50kn
MACHINE WEIGHT :
5300
MACHINE DIMENSIONS :
4.9x1.2x2.0
Description

0.5mm thickness PP cup Thin Wall Injection Molding Machine Servo System

Detailed Product Description

HIGH-SPEED INJECTION MOLDING MACHINE

It helps protect the system from fluid hammer.

This protects system components particularly pipe work, from both potentially destructive forces. An additional benefit is the additional energy that can be store while the pump is subject to low demand. These are often placed close to the demand to help over come restrictions and drag from long pipe work runs. An accumulator can maintain the pressure in a system for periods when these are slight leaks without the pump being cycled on an off constantly. when the temperature changes cause pressure excursions the accumulator helps absorb them.

These series machines take the accumulator to help inject, which having high cost performance improve the speed ,quicken the machine circle time, higher the efficiency, and especially suitable for the ultrathin

SPECIFICATIONS

SPECIFICATIONS
DESCRIPTION UNIT K2-170
INJECTION A B C
SHOT VOLUME CM3 277 318 392
SHOT WEIGHT G 260 298 368
(PS) OZ 9.1 10.5 12.9
SCREW DIAMETER MM 42 45 50
INJECTION PRESSURE MPA 190 166 135
SCREW L:D RATIO 21.5:1 20:1 18:1
SCREW STROKE MM 200
SCREW SPEED (STEPLESS) R/MIN 0~200
CLAMPING UNIT
CLAMPING FORCE KN 1700
OPENING STROKE MM 430
PLATEN SIZE MM*MM 680*680
SPACE BETWEEN TIE BARS MM*MM 460*460
MOLD THICKNESS (MIN-MAX) MM 200~530
MAX.DAYLIGHT MM 960
HYDRAULIC EJECTION STROKE MM 140
HYDRAULIC EJECTION FORCE KN 50
POWER UNIT
HYDRAULIC SYSTEM PRESSURE MPA 17.5
PUMP MOTOR(V/S) KW 15/18.5
HEATING CAPACITY KW 12.6
NUMBER OF TEMP CONTROL ZONES 4+(NOZZLE )
GENERAL
DRY-CYCLE TIME SEC 2
OIL TANK CAPACITY L 210
MACHINE DIMENSIONS MXMXM 4.9*1.2*2.0
MACHINE WEIGHT KG 5300

HYDRRULICS

Variable displacement pump System
Servo System
Oil suck filiter
Oil temperature control and alarm
By-pass oil filter

ELECTRONICS

8.7' lcd solor screen
200sets of mold memory
Barrel temperature monitoring and thermocouple break alarm
System hardware i/o testing function
Interface for printer and floppy drlver
Electric motor safety protection
Emergency stop safeguard device

RCCESSORIES
Adlustable machine leveling pads
Easily damaged spare parts
Professional tools
Manual

OPTIONRL DEVICE

Wide range of injection unit for specific appliaction
Spacific material screw and barrel
Accumulator fast injection
Core pull fittings
Air blast fittings
Glass water regulations
Extended nozzle
