Squeezing Plastic Recycling Machine PE Film Dryer 90KW Auto Heating / Cooling
Squeezing Plastic Recycling Machine PE Film Dryer 90KW Auto Heating / Cooling
Squeezing Plastic Recycling Machine PE Film Dryer 90KW Auto Heating / Cooling
Squeezing Plastic Recycling Machine PE Film Dryer 90KW Auto Heating / Cooling
Specifications
Brand Name :
XINTING
Model Number :
XT
Certification :
CE ISO9001
Place of Origin :
CHINA
Price :
NEGOTIATE
DRYING MATERIAL :
PE FILM
FUNCTION :
PLASTIC EXTRSION MACHINE
SCREW :
SINGLE SCREW OR DOUBLE SCREW
RAW MATERIAL :
WET PP PE MATERIAL
Application :
Plastic Recycling machine
Capacity :
300/500/1000kg/h
Description

Squeezing Plastic Recycling Machine PE Film Dryer 90KW Auto Heating / Cooling

Features:

1, Gearbox : ZLYJ315 (Guomao hardened gears)
2, Screw Diameter:φ300mm
3, Screw Length: 1300

5, Inverter Power: 90KW (DELTA)
4, Mainly Motor power:90KW 5,Inverter Power: 90KW (DELTA)
6, Screw and Barrel adopt 38CrMoAlA and nitriding treatment
7, Barrel heating power: 1zone*6KW=6KW, heating by electric
8, Capacity: 400~600kg/h.

9, Pelletizer(Cutting with 4 knifves) with Inverter : 2.2KW

10. diehead: Discharging hole diameter:12mm, copper pipe cooling

11, Air blower:3.0KW with transport pipe and stainless Storage Hopper: 300L capacity

12, Conveyor with inverter

13, Three-phase power: 380V/50HZ 14.water content <3%

Technical Parameters:

Model JM-250 JM-300
Motor Power 75KW 90KW
Gear Box Model Hard Teeth gear box (ZLYJ250) Hard Teeth gear box (ZLYJ315)
Screw Diameter 250mm 300mm
Screw Length 1320mm 1500mm
Screw Material 38CrMoAl,Nitriding Processing 38CrMoAl,Nitriding Processing
Air cooled motor 3kw 3kw
Storage Hopper 300L capacity 500L capacity
Moistures <3% <3%
Mold die Auto-heating and auto cooling Auto-heating and auto cooling
Dimenstion 3500*1350*1800MM Auto-heating and auto cooling
Weight 1800KGS 2000KGS
Capacity 300kg/h 500kg/h

Why you need it? ---- Dirty PE PP film

This squeezing dewatering machine for waste plastic recycle.Especially the agricultural film, they are dirty and often with clay, sand, grassroots, nails, wire, etc. So before granulation we have to clean and wash them.

Why you need it? ----Wet PE PP film

After clean and wash the dirty waste film, we have to squeeze the film. This squeezing dewatering machine for waste plastic recycle washing line is not only with high capacity but also with low energy consumption. The final moisture content can up to 3%. It will help you reduce the cost and improve productivity.

What advantage of it ?

It makes materials easier to be granulated and dry, and if you use it, you will do not need following three machines: dewatering machine, pipe drying system and agglomerator, only need one stage extruder recycling machine instead of two or three stage recycling machines

What to do?

Recycled aggregate can be used to production of agricultural film, PE can also be used to make fertilizer bags, garbage bags, agricultural renewable water pipe, fences, trees, POTS, barrels, dustbin, geotechnical material, etc

Squeezing Plastic Recycling Machine PE Film Dryer 90KW Auto Heating / Cooling

How to choose it ?

There are different capacity can be supplied: 200kg/h, 300kg/h, 500kg/h and 1000kg/h.You should choose different devices according to your material.According to your country condition, you may choose full automatic line or semi-automatic line.Our customer may purchase separate device based on his own conditions

Squeezing Plastic Recycling Machine PE Film Dryer 90KW Auto Heating / Cooling
