Specifications
Brand Name :
xinting
Model Number :
xt
Certification :
CE ISO9001
Place of Origin :
CHINA
MOQ :
1 set
Price :
NEGOTIATE
Payment Terms :
L/C, T/T
Supply Ability :
20 set per month
Delivery Time :
60 days
Packaging Details :
film package
Usage :
water proof high way project
power :
156kw
dimension :
16*2.6*3.2m
machine: :
Plastic drainage panel machine
width :
800-3000mm
material :
HDPE
Description

Plastic drainage panel production line, waterproof material machine; widely used for project of highway

production line, waterproof material machine; widely used for project of highway, railway and bridge, have following features:
1) The machine is a new product which is developed and designed by ourselves and fills the domestic blank in the field;
2) Is specially used for producing PE high strength carbon waterproof structure plate;
3) Because of its excellent physical capacity, such as light weight, high strength of resistant pressure, waterproof and damp proof, absorbing load of strike and vibration, sound insulation and so on, the plate is widely used for project of highway and railway, project of bridge and tunnel and project of underground.

Specification Plastic drainage panel production line, waterproof material machine; widely used for project of highway:

1. CE/SGS certificate
2. Width:800-3000mm
3. Thickness:5-10mm
4. HDPE material

Technical data sheet for Plastic drainage panel production line, waterproof material machine; widely used for project of highway

Model XT-FWB300 XT-FWB600 XT-FWB1000
Extruder Φ65/28 Φ90/30 Φ120/33
Screw dia. mm Φ65 Φ90 Φ120
Width of panel mm 300 600 1250
Thickness of panel mm 20-50 20-50 20-50
Type of panel A:single-side B:double-side
Installed capacity (approx) KW 73 88 126
Dimensions (L×W×H) (approx) m 15×1.2×2.8 20×1.8×3.2

30×2.2×3.5

Waterproof Plastic Sheet Making Machine HDPE Drainage Panel Production Line

Waterproof Plastic Sheet Making Machine HDPE Drainage Panel Production Line

Product introduction:

Waterproof and drainage board production line is our newest product. Our technicist innovate in traditional sheet machinery, made it is suitable for production of HDPE honeycomb drainage plate. Waterproof drainage board has the character of high resistant to pression, anti-corrosion, acid-base resistance and chemical to corrode, the roots of plants sting, does not decompose, so it has a long service life. HDPE waterproof and drainage board is a kind of high durability waterproof and drainage material that will not affact from the external influence generally, This environmental protection material won't damage to underground water sources, ecological environment, human health and the environment.
HDPE waterproof and drainage board brought a leading global new design concept, that is, through professional waterproof design, professional guide water planning and comprehensive protection, to achieve the overall protection system security goals. The design principle is through the special concave and convex double-glazing structure, and adopt reliable and simple connections (adhesive or welding), to achieve the overall protection, waterproof and drainage, and other functions.
HDPE waterproof and drainage plate is easy installation, no degradation, and it has good flexibility, resistance to plant root puncture, accord with environmental protection requirement, ensure that underground water safety and ecological balance. Polyethylene (HDPE) waterproof and drainage plate is the first muti_function coil material that can provide comprehensive protection for system, professional waterproof and drainage. As the raw material, HDPE ensure products all the best function.

Delievery:

Waterproof Plastic Sheet Making Machine HDPE Drainage Panel Production Line
