Waste PET Bottle Recycling Machine Bottle Flakes Cleaning Line Automotive
Waste PET Bottle Recycling Machine Bottle Flakes Cleaning Line Automotive
Specifications
Brand Name :
XINTING
Model Number :
19
Certification :
CE ISO SGS
Place of Origin :
CHINA
MOQ :
1 SET
Price :
NEGOTIATE
Supply Ability :
10 SET PER YEAR
Delivery Time :
40DAYS
Packaging Details :
WOODEN PACKAGE FILM PACKAGE
MATERIAL :
pe pp PET bottle beverage bottle plastic bricks
Product Type :
pe pp PET bottle washing
width :
5-25mm
thickness :
0.4-1.3mm
save labor :
3 people
operation fast: mold :
5 minutes
keywords :
Hot sale 500kg/h PET recycling machine / pet bottle recycling plant good price / pet flake washing line
Application: :
plastic strap FOR PET PP pe
Description

washing machine for waste pet bottle flakes/high quality bottle flakes cleaning line price

Description:
PET Plastic recycling machine is mainly used for crushing, washing, palletizing of PET bottles to realize auto separation for caps and labels: belt conveyer, crusher, steam washer, scrubbing washing unit, rinsing and precipitation washing unit, centrifugal dewatering unit, hot air flow drying unit, and electric control cabinet. Which capability arrange 300-3000KG/h.


Main Advantages:
1. Automotive line for recycling the PET bottles and other waste plastic profile, except the film.
2. The final product is the cleaning flakes, if you want the final product is pellets, we should equip the granulator line again.

Composition of PET Bottle Bale:

Description Recycling machinery
PET Containers One-way bottles
Colors Fraction PET bottles should be pre-sorted by color. If the percentage of color bottles is higher than 30%, we suggest customer to install the automatic color bottle sorting machine to achieve efficiency.
Base Cups Included, if any, and should be PP or PE plastic.
Labels (shrunk or glued) The production line is designed for removing label mechanically. All type of labels will be removed by mechanical action. It includes paper, BOPP, PET, PVC, etc.
Caps PP, HDPE
Caps seals EVA, PP ( floatable material ) PVC or rubber seals are not separable.
Glue Hot melt, water borne.
Contamination Mixed with the bottles could be present contaminations coming from the collection and storage of the postconsumer bottles or made by consumer. These contaminations include mud, sand, soil, glass, organics, paper, residual liquid, etc. Total contamination content should not exceed 10%.
Total Non-PET Containers Non-PET containers max 2% of which
PVC Container 0.5 -1% max
Polyolefins Container 3 % max. It will only affect the output volume but not quality of end product.
Wrong PET Colors and Opaque 1-2% max
Glass and Ceramic (metals excluded) 0.5 -1% max
Magnetic Metals 0.5 - 1% max
Aluminum and Non Magnetic Metals

0.5 - 1% max All kind of metal will be separated before crushing


Process flow:
Bale opening machine→Belt conveyor→Label stripper→Separating conveyor→Belt conveyor→Crusher→Screw conveyor→Boiler→Screw conveyor→Friction cleaning machine→Fulling mill→Screw conveyor→Twin-screw washing tank→Twin-screw washing tank→Centrifugal dewatering machine→Heating dryer→Blowing conveyor


Features:
Capacity: 300—3000kg per hour
Moisture of PET Flakes: Less Than 2%
Cap &Label separate with the PET bottle flakes automatically
Bottle Types: PET Bottle, Plastic Bucket, Water Bottle, Coke Bottle,
Application: PET Strap, PET Yarn Fiber
CE Standard: Provide Turn Key Solution.
