Dual Row H12.95 SMT 2.54 Mm Pin Header Waterproof Right Angle
Dual Row H12.95 SMT 2.54 Mm Pin Header Waterproof Right Angle
Dual Row H12.95 SMT 2.54 Mm Pin Header Waterproof Right Angle
Dual Row H12.95 SMT 2.54 Mm Pin Header Waterproof Right Angle
Dual Row H12.95 SMT 2.54 Mm Pin Header Waterproof Right Angle
Dual Row H12.95 SMT 2.54 Mm Pin Header Waterproof Right Angle
Specifications
Brand Name :
soulin
Model Number :
2.54mm pitch ejector header
Certification :
ISO9001&ISO14001
Place of Origin :
China
MOQ :
2000
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
1kk/months
Delivery Time :
14days
Packaging Details :
tube/box/reel and tape/bag
Material :
plastic
type :
straight/right angle /SMT
Color :
black 、grey
pitch :
2.54mm
MOQ :
2000PCS
PAYMENT :
T/T
Description

Dual Row H12.95 SMT 2.54 Mm Pin Header Waterproof Right Angle

  • Horn connector is widely used in vehicle monitoring, instrumentation, Internet of things, new energy vehicles, LED display field, POS machine and scanner, lighting industry, security industry, electronic toys, household appliances, etc., to provide the most reliable connection board to board and line to board.

    The spacing can be roughly divided into: 1.27mm, 2.00mm, 2.54mm

    The number of rows can be roughly divided into: double rows

    Ear buckle can be roughly: long ear buckle, short ear buckle.

  • High temperature resistant insulating plastic (UL94V-0) material: PBT(only meet the wave soldering process).

    High temperature resistant insulating plastic (UL94V-0) material: PA6T, PA9T, LCP(can meet the wave soldering, reflow welding two kinds of process).

    The color of insulating plastic can be divided into black, white, blue, natural color and so on.

    Policy material: Brass (H65)

    Hardware plug contact terminal surface treatment: first plated with nickel in gold or silver, bright tin, wuxi, semi-gold tin etc.

Platsic material PA6T/PA9T/LCP+30%G.F
Color black
Insrlator material POLYESTER(UL94V-0)
Contact material brass
Contact plating AU OR SN OVER NI
Current rating 3.0Amps
Withstanding Voltage AC/DC500Vmin/Minute
Insulation Resistance 1000MΩ Min
Contact Resistance 20mΩ MAX
Operation Temperature -40℃+105℃

Dual Row H12.95 SMT 2.54 Mm Pin Header Waterproof Right Angle
