Unique Plate Plate Type Heat Exchanger Parts Black Color Simple Structure K34
Unique Plate Plate Type Heat Exchanger Parts Black Color Simple Structure K34
Specifications
Brand Name :
M&C
Model Number :
K34
Certification :
SGS FDA ISO
Place of Origin :
Jiangsu China (mainland)
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000Pcs/Month
Delivery Time :
5-8 working days
Packaging Details :
Standard export carton /wooden case
Product Name :
Unique Plate Plate Type Heat Exchanger Parts
Material :
NBR/EPDM/SILICONE/VITON
Application :
PHE parts
Packing :
Standard export carton
Warranty :
1 year
Color :
Black
Description

Product Details

Diverse Plate Models

We have almost 150 models for detachable plate heat exchanger. The plate angle is distinguished between high theta and low theta, chevron is divided into shallow groove. Deep groove and super-deep groove which can be assembled to narrow passage PHE, wide passage PHE and super-wide passage PHE in order to be applied in different fields and fluids.

Unique Plate Design

We design efficient heat transfer plate based on super tinny digital precise measuring and test method. The unique chevrons of plates along with reasonable plate mould design improve heat transfer efficiency.

Mix Design

MC plates with H theta and L theta which can achieve the thermal mix design.

High heat transfer performance and pressure drop

Lower heat transfer performance and pressure drop.

Specifications

Plate Material SS304 SS316L Titanium SMO254 C276
Plate Thickness 0.5/0.6/0.8/1.0mm
Gasket Material

NBR (applicable temperature -15~120℃)

HNBR (applicable temperature -15~160℃)

EPDM (applicable temperature -25~150℃)

HEPDM (applicable temperature -25~170℃)

Viton/FKM (applicable temperature -5~220℃)

NEOPREKE (applicable temperature -5~130℃)

VNQ (applicable temperature -65~250℃)

Unique Plate Plate Type Heat Exchanger Parts Black Color Simple Structure K34

Our Service

1. Inquiry and consulting support.

2. Sample testing support.

3. Visit our Factory.

After-sales Service

1. Training how to install the machine, training how to use the machine.

2. Engineers available to service machinery overseas.
