Programmable Room Heated Floor Thermostat 16A NTC Sensor With PC Housing
Programmable Room Heated Floor Thermostat 16A NTC Sensor With PC Housing
Programmable Room Heated Floor Thermostat 16A NTC Sensor With PC Housing
Programmable Room Heated Floor Thermostat 16A NTC Sensor With PC Housing
Programmable Room Heated Floor Thermostat 16A NTC Sensor With PC Housing
Programmable Room Heated Floor Thermostat 16A NTC Sensor With PC Housing
Programmable Room Heated Floor Thermostat 16A NTC Sensor With PC Housing
Programmable Room Heated Floor Thermostat 16A NTC Sensor With PC Housing
Specifications
Brand Name :
Saiko
Model Number :
SK51
Certification :
CE
Place of Origin :
Jiangsu
MOQ :
64PCS
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
3000PCS/WEEK
Delivery Time :
3-5 workdays
Packaging Details :
64PCS/CTN (CTN SIZE:435*395*290mm)
Type :
Floor heating Systems
Voltage :
AC230V, 50Hz
Current load :
16A
Setting range :
+5~+90℃
Floor sensor :
Rubber-thermoplastic NTC sensor
Housing material :
Self-extinguishing PC
Description

Electronic weekly programmable room thermostat for floor heating
Weekly circulation, it is possible to set 6 periods called events each day with different temperatures, also you can select "manual mode" or "temporary control mode" according to your individual requirements. The thermostat is recommended for the control of electric heating devices or on/off valve actuator used in water-based heating systems.

Features
Switches on your heating system at predetermined times on different days of the work.
Comes with a preprogrammed schedule that is suitable for most installations. However, you can customize this program any time you wish.
Allows you to reset the thermostat to factory settings.
Technical data
Power SupplyAC200-240VAC 50/60HZ
Accuracy±0.5ºC
Probe sensorNTC Sensor
Power Consumption<1W
Load current3A(water heating),16A(electric heating)
Temperature Adjustable Range5°C~90°C( can adjust to 35°C~90°C)
Limit Temperature Range5°C~60°C( factory setting: 35°C)
OutputSwitch relay
Insulating conditionNormal environment
Running programSet per 1 week as a cycle
InstallationWall mounted
ApplicationWater Floor Heating System
Electric Floor Heating System
Infrared Heater System
CertificateCE,RoHS


Selection Table

SK51.7133ABuilt-in& floor sensor, floor limit sensor, weekly programming
SK51.7233ABuilt-in& floor sensor, floor limit sensor, weekly programming. A potential-free output
SK51.71616ABuilt-in& floor sensor, floor limit sensor, weekly programming


Advanced setting (qualified person preferred)
When the thermostat is turned off, You can press"Menu" and turn on it at the same time ,then you can enter the mode of advanced setting.

SymbolSetting Up or Down
1ADJTemperature calibration

Adjust measured temperature

2SENSensor mode

IN: built-in sensor
OUT: floor sensor
ALL: both sensors

3.LITLimitation temperature

Adjust limitation value,
Limitation range:5℃~60℃

4DIF

Switching
differential

Adjust switching differential
5LTPAntifreeze functionTurn on/off Anti-frozen function
6PRGSet vacation mode

00: 5/2 day mode

01: 6/1 day mode
02: 7 day mode

7RLEPotential- free output and main power output in the same/different way

Change the present

linkage way

8DLYDelay time of Potential- free outputChange linkage delay time
9HITMax temperatureLimitation temperature setpoint
AFACReset to factory settingsPress""and hold for 5s,all parameters will be reset


Programmable Room Heated Floor Thermostat 16A NTC Sensor With PC Housing
Programmable Room Heated Floor Thermostat 16A NTC Sensor With PC Housing
Programmable Room Heated Floor Thermostat 16A NTC Sensor With PC Housing

Sensor failure
Please select the right sensor mode when operation, it will display the "Err" symbol on screen far sensor failure, thermostat must be checked till the fault is eliminated
