Specifications
Brand Name :
Saiko
Model Number :
SKQA
Certification :
CE
Place of Origin :
Nanjing,China
MOQ :
10 sets
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
2000sets/week
Delivery Time :
3-15 work days
Packaging Details :
one set in one white box, 20 sets in one carton
Valve type :
2-way/3-way ball valve
Pressure class :
PN16(1.6Mpa)
Fluid temperature :
2ºC~90ºC
Ambient temperature :
<65 centigrade
Relative humidity :
max 95%
Protection class :
IP55
Description

2Way , 3Way Brass Motorized Ball Valve Brass Electric Motor Operated Ball Valve

SKQA series of 2-way and 3-way motorised ball valves intened for use in heating and cooling systems. Suitable for hot and chilled water.

Models

SQA15 2-way, DN15 (15mm), 3-wire; SQA15-3 3-way, DN15 (15mm), 3-wire

SQA20 2-way, DN20 (20mm), 3-wire; SQA20-3 3-way, DN20 (20mm), 3-wire

SQA25 2-way, DN25 (25mm), 3-wire; SQA25-3 3-way, DN25 (25mm), 3-wire

SQA25 2-way, DN32(32mm), 3-wire;

Features

Smooth flow, no clog

Suitable for any specifications of fan coil unit.

The power is cut off when the valve reaches the on/off position. This ensures long life service for the actuator.

The actuator cover adopts close strcuture which is resistive to humidity and ensures reliable operation for motor.

Technical data

Valve type 2-way/3-way ball valve
Pressure class PN16(1.6Mpa)
Supply voltage 220VAC±15%, 50/60Hz, 110V, 24V
Connection G(inner thread)
Fluid temperature 2ºC~90ºC
Ambient temperature <65 centigrade
Relative humidity max 95%
Valve body Bronze
Protection class IP55
Power consumption 6W(only when valve position is changed)
Opening and closing time 16S/50Hz,12S/60Hz
