Extruded High Copper Radiator Finned Tubes With 10.5mm Fin Height
Extruded High Copper Radiator Finned Tubes With 10.5mm Fin Height
Extruded High Copper Radiator Finned Tubes With 10.5mm Fin Height
Extruded High Copper Radiator Finned Tubes With 10.5mm Fin Height
Specifications
Brand Name :
Reliance
Model Number :
DR
Certification :
CE,ISO...
Place of Origin :
China.Imported materials are available.
MOQ :
N/A
Price :
N/A
Payment Terms :
T/T, L/C
Supply Ability :
Daily capacity up to 15,000 Meters.
Delivery Time :
Ex-work within 1 month on receipt of order.
Packaging Details :
(1) Steel frame case sealed by plywoods with each end capped. (2) Solid fumigated wooden box with each end capped.
Company Type :
Manufacturer,Importer & Exporter
Fin tube Type :
Extruded fin tube , Extrusion finned tube
Tube material :
Carbon steel, stainless steel, alloy steel, copper etc...
Fin material :
Aluminum, copper and steel
Fin tube length :
No limit
Fin height :
16mm Max.
Accessories :
Tube support box, Clamp & Spacer box
Packing :
Wooden box / Steel frame steel case
Description

Extruded high copper radiator finned tubes with 10.5mm fin height


Detail:

General extrusion production capacity General specifications of DR Type-Extruded Fin Tubes

Extrusion Facility: 14 finning machines.
Daily capacity up to 15,000 meters.
Extruded fins type: solid and serrated.

Tube OD : 50.8mm(2'') max.
Tube Length : no limit
Fin Height : 16 mm max.
Fin Thk : 0.4mm
Fin Pitch : 1.5mm min.


Description:
Manufacturing Process
A smooth core tube is inserted into an aluminum sleeve and then the fins are extruded out of the aluminum sleeve.

Fins Type:
Solid fins & Serrated fins

Accessories
Tube Support Box, Clamp or Spacer Box(Materials: Aluminum, Zinc or Stainless Steel).

Applications:

The common application fileds are:

  1. Heat exchangers units for power plant(electric, nuclear, thermal and geothermal power plants);
  2. High corrosive systems (condensers, evaporators, sea water desalinations, fertilizing, urea systems, ammonia, gas, corrosive acids);
  3. The petroleum, chemical and petrochemical industries;
  4. The food processing and refrigeration industries;
  5. Natural gas treatment;


Specifications:

Extruded Bimetallic Finned Tube is combined with two different materials.

Items General Materials Popular ASTM Materials
Core Tube Material

Any metallic materials, as carbon steel, low-alloy steel, stainless steel, brass, copper, cooper-nickel alloys, aluminum bronze, nickel alloys etc.
(Core tube with extremely thin wall materials can be applied.)

1. Carbon Steel: A179, A192,SA210 Gr A1/C,A106 Gr B
2. Stainless Steel: TP304/304L,TP316/TP316L/316Ti,
A789 S31803/S2205 etc...
3. Copper:UNS12200/UNS14200/UNS70600,
CuNi70/30,CuNi 90/10
4. Titanium: B338 Gr 2
Fins Material

1. Aluminum
2. Copper.

1. Aluminum(Alu.1100,Alu.1060,Alu.6063)
2. Copper.


All dimensions are in Inches and specification upon your requests.

Tube OD

Fin Height

Fin Thickness

Fins per Pitch(Density)

5/8

3/8,1/2

.015/.016/ .020

4, 5, 6, 7, 8, 9, 10, 11, 12

3/4

3/8,1/2,5/8

.015/.016/ .020

4, 5, 6, 7, 8, 9, 10, 11, 12

1

3/8,1/2,5/8

.015/.016/ .020

4, 5, 6, 7, 8, 9, 10, 11

1 1/4

3/8,1/2,5/8

.015/.016/ .020

4, 5, 6, 7, 8, 9, 10,

1 1/2

3/8,1/2,5/8

.015/.016/ .020

4, 5, 6, 7, 8, 9, 10, 11

1 3/4

3/8,1/2,5/8

.015/.016/ .020

4, 5, 6, 7, 8, 9, 10

2

3/8,1/2,5/8

.015/.016/ .020

4, 5, 6, 7, 8, 9, 10

Please email us for more information.
