ASTM B111/ B111M Copper Alloy Seamless Condense L/LL/KL Type Fin Tube
ASTM B111/ B111M Copper Alloy Seamless Condense L/LL/KL Type Fin Tube
ASTM B111/ B111M Copper Alloy Seamless Condense L/LL/KL Type Fin Tube
ASTM B111/ B111M Copper Alloy Seamless Condense L/LL/KL Type Fin Tube
Specifications
Brand Name :
Reliance
Model Number :
L TYPE
Certification :
CE,ISO...
Place of Origin :
China
MOQ :
N/A
Price :
N/A
Payment Terms :
T/T, L/C
Supply Ability :
Daily capacity up to 5,000 Meters
Delivery Time :
Ex-work within 4 weeks after order.
Packaging Details :
Steel frame case sealed by plywoods with each tube end capped
Compamy Type M :
manufacturer, Importer & Exporter
Fin Tube Type :
L Type Fin Tube,Tension Wound L Type Fin Tube
Origin :
China
Nearest Port :
Shanghai Port, China
Description

ASTM B111/ B111M Standard Copper Alloy Seamless Condense L Type finned tube

Quick Detail:

(1) ASTM B111/ B111M : Standard Specification for Copper and Copper-Alloy Seamless Condenser Tubes and Ferrule Stock

(2) Manufacturing process:

The copper strip is folded into an L SHAPE and wound onto the base tube surface under tension.

The feet of the fins are joined together and cover the finned surface.

(3) Delivery Condition

Tube ends are square cut, free burrs, internally dried and air blown clean.

(4) Packing

The desiccants are put into each package for continental transportation as well.

(5) Applications

An urgent replancement job during the shutdown of power plant.

(6) Other Specifications

All dimensions are in Inches and specification upon your requests.

Tube OD

Fin Height

Fin Thickness

Fins per Pitch

5/8

3/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

3/4

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1 1/4

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1 1/2

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

Pease email us for more information.
