600V PVC Heat Shrink Tubing , Imitation Wood Battery Pack Shrink Tube
600V PVC Heat Shrink Tubing , Imitation Wood Battery Pack Shrink Tube
600V PVC Heat Shrink Tubing , Imitation Wood Battery Pack Shrink Tube
600V PVC Heat Shrink Tubing , Imitation Wood Battery Pack Shrink Tube
600V PVC Heat Shrink Tubing , Imitation Wood Battery Pack Shrink Tube
600V PVC Heat Shrink Tubing , Imitation Wood Battery Pack Shrink Tube
600V PVC Heat Shrink Tubing , Imitation Wood Battery Pack Shrink Tube
600V PVC Heat Shrink Tubing , Imitation Wood Battery Pack Shrink Tube
Specifications
Brand Name :
UPTOGETHER
Model Number :
PVC DRS
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
50 Kilogram/Kilograms
Price :
$2.00 - $6.00 / Kilograms
Payment Terms :
L/C, T/T
Supply Ability :
1000 Kilogram/Kilograms per Day
Delivery Time :
1-15 days
Packaging Details :
Carton
Material :
PVC
Rated Voltage :
1kV , 600V
Standard Color :
Black,White,Yelllow,Red,Green,Clear,Grey,Brown,Wood
Type :
Heat Shrinkable
Usage :
Insulation Protection
ID :
1-180mm
Description

PVC Imitation Wood Heat Shrink Tubing , Material PVC , φ2-φ180mm

1. Product Introduction

PVC imitation wood heat shrink tubing is produced with excellent and environmental protective PVC colloidal particle and with imitation surface after a special processing, treated by evaporation , then extruded to tubing when heated up and liquated by extruding machine , and coiling packed after cooling . PVC heat shrinkable tubing possesses excellent flexibility , mechanical and dielectric capability , flame resistance , low temperature shrinkage etc . PVC imitation wood heat shrink tube is more suitable for package of battery and other ornament usage .

600V PVC Heat Shrink Tubing , Imitation Wood Battery Pack Shrink Tube

2. Technical Parameter

2.1 Shrink Ratio
S=[(Lo-L)/Lo]х100% △S=(max-Lmin/Lo)х100%
2.2 Electrical Performance
Volume Resistivity 1x1015Ω/cm3
Wall Thickness breakdown voltage
0.07-0.09 ≥6kV
0.10-0.12 ≥8kV
0.15-0.20 ≥10kV
2.3 Mechanical Performance
Tensile Strength≧40Mpa/cm
Angle Tear Strength≧75KN/m
2.4 Heat Resistence
85℃х1000h No Crack
3. Specification Packaging
No. Size Fold Diameter Wall Thickness 100℃ Longitudinal Shrinkage % 160℃ Longitudinal Shrinkage %(105℃ tube) 100℃lateral shrinkage % Weight for 100M
85℃ 105℃ Type I Type II 85℃ 105℃
1 Ф2.0 3.5+0.5 0.08±0.015 0.085±0.015 12±3 0.08
2 Ф2.5 4.2+0.5 0.10
3 Ф2.8 4.7+0.5 0.11
4 Ф3.0 5.0+0.5 7±3 ≤20 45±5 0.12 0.13
5 Ф3.2 5.5+0.5 0.13 0.14
6 Ф3.5 6.0+0.5 0.14 0.15
7 Ф4.0 7.1+0.5 12±3 7±3 ≤20 48±5 0.16 0.17
8 Ф4.5 8.0+0.5 0.19 0.20
9 Ф5.0 8.7+0.4 0.20 0.22
9.0+0.4 0.21 0.23
9.3+0.4 0.22 0.24
10 Ф6.0 10.5+0.5 0.09±0.015 0.24 0.27
10.8+0.5 0.25 0.28
11.1+0.5 0.26 0.29
11 Ф7.0 12.0+1.0 0.28 0.31
12 Ф8.0 13.5+0.5 0.31 0.35
13.8+0.5 0.32 0.36
14.1+0.5 0.33 0.37
13 Ф9.0 15.0+1.0 0.35 0.39
14 Ф10 16.5+0.5 0.10±0.02 0.47
16.8+0.5 0.48
17.1+0.5 0.49
15 Ф11 18.0+1.0 0.52
16 Ф12 20.0+1.0 0.58
17 Ф12.5 21.0+1.0 0.60
18 Ф13 21.5+1.0 0.62
19 Ф13.5 22.5+1.0 0.65
20 Ф14 23.5+1.0 0.68
21 Ф14.5 24.0+1.0 0.70
22 Ф15 24.5+1.0 0.71
23 Ф16 26.5+0.5 0.75
27.0+0.5 0.76
24 Ф16.5 27.0+1.0 0.77
25 Ф17 28.0+1.0 0.79
26 Ф18 29.0+1.0 0.10±0.02 0.12±0.02 0.82 0.98
27 Ф19 31.0+0.6 0.87 1.04
31.4+0.6 0.88 1.06
28 Ф20 32.5+1.0 0.12±0.02 1.11
29 Ф21 34.0+1.0 1.16
30 Ф22 35.5+1.0 1.22
31 Ф23 36.5+1.0 1.28
32 Ф24 39.0+1.0 1.32
33 Ф25 41.0+1.5 1.44
34 Ф25.4 41.5+1.5 1.45
35 Ф26 43.5+1.5 1.48
36 Ф27 45.0+1.5 1.52
37 Ф28 46.5+1.5 1.58
38 Ф29 48.0+1.5 0.15±0.025 15±3 10±3 ≤20 48±5 2.07
39 Ф30 50.0+1.5 2.13
40 Ф33 52.0+1.5 2.22
41 Ф34 56.5+1.5 2.42
42 Ф35 58.0+1.5 0.15±0.025 15±3 10±3 ≤20 48±5 2.48
43 Ф36 59.5+1.5 2.54
44 Ф38 63.5+1.5 2.71
45 Ф40 65.0+2.0 0.15±0.03 0.18±0.03 2.77 3.22
46 Ф41 67.0+2.0 2.86 3.43
47 Ф42 69.0+2.0 2.95 3.54
48 Ф45 72.5+2.0 3.10 3.72
49 Ф46 74.0+2.0 3.20 3.84
50 Ф48 77.5+2.0 3.36 4.03
51 Ф50 82.0+2.0 3.58 4.23
52 Ф55 90.0+2.0 3.88 5.65
53 Ф60 97.0+2.0 0.20±0.035 5.50
54 Ф65 106.0+2.0 6.00
55 Ф70 112.0+2.0 0.20±0.04 6.35
56 Ф75 122.0+2.0 6.92
57 Ф80 131.0+2.0 7.54
58 Ф85 135.0+2.0 18±3 12±3 ≤20 7.76
59 Ф93 143.0+2.0 8.22
60 Ф98 150.0+3.0 8.63
61 Ф103 160.0+3.0 9.15
62 Ф109 167.0+3.0 9.51
63 Ф116 178.0+3.0 10.20
64 Ф130 198.0+4.0 11.30
65 Ф142 218.0+4.0 12.40
66 Ф154 238.0+4.0 13.40
67 Ф161 248.0+4.0 14.00
68 Ф167 258.0+4.0 14.60
69 Ф180 278.0+4.0 15.70

The tube should avoid exposure and heat source in transit and store.Quality guarantee period is one year.

4. Ordering Information

Packing
1. By diffrent cartons and plastic pallents.

2. Anonymous packing is available.

3. OEM packing is available.

4. Do as customer's requirements.

Delivery
1. Our factory is nearby Shanghai.

2. Other seaport is acceptable.

3. Do as customer's requirements.

5. Application Case
