Low Hazard Heat Shrink Insulation Tube 100mm Low Smoke Cable Identification Sleeve
Low Hazard Heat Shrink Insulation Tube 100mm Low Smoke Cable Identification Sleeve
Specifications
Brand Name :
Long
Model Number :
20.1
Certification :
ISO
Place of Origin :
China
MOQ :
1piece
Price :
0.05
Payment Terms :
T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability :
400000meters per day
Delivery Time :
1-9days
Packaging Details :
Roll/Carton
MOQ :
1piece
Colour :
Yellow
Operating temperature range :
-55~+120°C
Minimum recovery temperature :
110°C
Maximum storage temperature :
40°C
Shrink ratio :
2:1
Printing mode :
Single sided printing and Double sided printing formats available
Supplied mode Recommended Printers :
Recommended Ribbons
Description

Black Halogen Free Low Smoke Low Hazard Identification Sleeves

Halogen Free Low Smoke Low Hazard Identification Sleeves
Description: HNF marker sleeve is a flattened, heat-shrinkable tubing designed for wire and cable harness identification. It can also be used for applications where limited fire hazard characteristics are necessary. The zero halogen material coupled with low smoke and low toxic fume emissions make this product perfectly used in enclosed spaces such as mass transit, marine and industrial installations.
Standard : NF F16-101, DIN5510-2, BS6853, EN45545-2, SAE-AS 81531, MIL-STD- 202F/Method 215J, RoHS .FPA130.

Features

Material
Application range

The sleeving shall be fabricated from irradiated, thermally stabilized and flame retarded modified polyolefin compound containing no halogens or cadmium in the formulation.
Industrial environment; Rail & mass transit; Aerospace & defense; Marine;

Operating temperature range-55~+125°C
Minimum recovery temperature+115°C
Maximum storage temperature+40°C
Shrink ratio2:1
ColorWhite, Yellow, other color is available if ordered
Printing modeSingle sided printing and Double sided printing formats available

Supplied mode
Recommended Printers

Either Continuous type or Ladder format type is available Thermal transfer printer
Recommended RibbonsN85 resin ribbon, Black, 100mm(width)*300m(length)

Dimensions

Part NumberAs Supplied (mm)After Recovery(mm)

ID

(D)

Flatten Width

(W)

Double Wall Thickness

ID

(d)

Single Wall Thickness
HNF-M-2X-2.4-2.79±0.205.0±0.30.48±0.10W1.180.49±0.06
HNF-M-2X-3.2-3.64±0.236.3±0.40.48±0.10<1.590.51±0.06
HNF-M-2X-4.8-5.26±0.258.9±0.40.49±0.10W2.360.54±0.06
HNF-M-2X-6.4-6.92±0.2811.5±0.40.50±0.10W3.180.56±0.06
HNF-M-2X-9.5-10.2±0.3216.7±0.50.51±0.11W4.750.59±0.06
HNF-M-2X-12.7-13.5±0.3621.8±0.60.52±0.11W6.350.60±0.07
HNF-M-2X-19-20.1±0.4032.2±0.60.53±0.11<9.530.62±0.07
HNF-M-2X-25-26.7±0.4542.5±0.70.55±0.12<12.70.63±0.07
HNF-M-2X-38-39.8±0.5163.2±0.80.57±0.12W19.10.64±0.07


Package Information

Ordering Size (HNF-M-2X)Ladder Format TypeContinuous Type
A&B-Small Box Packing (PCS/Box)A-Paper reel Packing (m/reel)B-Plastic reel Packing (m/reel)
0)2.425005025
023.2200010025
(P4.8200010025
(P6.4200010025
(P9.5100010025
012.7100010025
01950010025
02550010025
0385005025



Low Hazard Heat Shrink Insulation Tube 100mm Low Smoke Cable Identification Sleeve

FAQ

Professional Production Quality is Reliable

Q1 . Which certifications or test reports do you have?

A : We have UL,ROHS and REACH.

Q2 . How to ship my order? Is it safe?

A : For small package, we will send it by Express,such as Fedex, UPS,TNT, DHL and so on.

For big packages, we will send them by Air or By sea or by Train. We will use good packing and ensure the safety. We will be responsible to any product damage caused on delivery.”

Q3 . What about your delivery time?

A : We have a lot of products in stock. We can send the stock products in 3 work days.

If without stock,or stock is not enough, we will check the delivery time with you.” (Usually is 3-7days).

Q4 . Can you provide samples? Are the samples free?

A : Yes. We can provide samples.

Usually for our standard products with stock, we can supply samples free for testing.

Q5 . Could I put my own logo on it?

A : Sure, of course, we are a professional manufacture and have over 10 years OEM experience.
