3x Dual Wall Heat Shrink Tube Halogen Free 12.7mm Red Tubing
3x Dual Wall Heat Shrink Tube Halogen Free 12.7mm Red Tubing
3x Dual Wall Heat Shrink Tube Halogen Free 12.7mm Red Tubing
3x Dual Wall Heat Shrink Tube Halogen Free 12.7mm Red Tubing
3x Dual Wall Heat Shrink Tube Halogen Free 12.7mm Red Tubing
3x Dual Wall Heat Shrink Tube Halogen Free 12.7mm Red Tubing
Specifications
Brand Name :
Long
Model Number :
12.7mm
Certification :
ISO
Place of Origin :
China
MOQ :
1BOX
Payment Terms :
T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability :
400000meters per day
Delivery Time :
1-9days
Packaging Details :
Roll/Carton
Color :
Red and Black
Material :
PE
Shrink ratio :
3:1
Halogen :
Halogen free
Super sealing against :
water, moisture or other contaminates
Continuous operating temperature :
-45°C-125°C
Fully shrink Temperature :
^125°C
Compliant :
Sony compliant
Description

Box Packing Dual Wall Heat Shrink Tubing With Adhesive Shrink Ratio 3X

Adhesive lined heat shrink tubing with environmental sealing capability for a wide variety of electrical applications, including automotive and marine wire harness, wire splices, breakouts, and connector-to-cable transitions.

Features

• 3:1 shrink ratio

• Halogen free

• Super sealing against water, moisture or other contaminates

• Continuous operating temperature:-45°C-125°C

• Fully shrink Temperature:^125°C

• Shrink ratio: 3:1

• Sony compliant

Dimensions

Size Expanded After Recovery Standard Package
Inch mm Internal Diameter mm Internal Diameter mm Total Wall Thickness mm Adhesive Thickness mm Spool Length M/spool
3/32 2.4 2,4 0.8 0.85±0.15 0.40±0.10 200
1/8 3.2 3,2 1.0 0.95±0.15 0.40±0.10 200
3/16 4.8 4,8 1.6 1.10±0.15 0.40±0.10 100
1/4 6.4 6,4 2.2 1.20±0.15 0.45±0.12 100
5/16 7.9 7,9 2.7 1.35±0.15 0.50±0.12 100
3/8 9.5 9,5 3.2 1.45±0.20 0.50±0.12 50
1/2 12.7 12,7 4.2 1.70±0.20 0.50±0.12 1.22OR25M/R0II
5/8 15 15 5.2 1.80±0.20 0.55±0.15 1.22OR25M/Roll
3/4 19.1 19,1 6.3 2.00±0.20 0.55±0.15 1.22OR25M/Roll
1 25.4 25,4 8.5 2.10±0.25 0.55±0.15 1.22OR25M/R0II
1-1/4 30 30 10.2 2.20±0.25 0.60±0.15 1.22 OR25M/Roll
1-1/2 39 39 13.5 2.40±0.25 0.60±0.15 1.22OR25M/Roll
2 50 50 17 2.70±0.25 0.70±0.15 1.22OR25M/R0II
5/2 64 64 21 3.00±0.30 0.70±0.15 1.22OR25M/Roll
3 75 75 25 3.00±0.30 1.00±0.20 1.22OR25M/Roll
7/2 90 90 30 3.00±0.30 1.00±0.20 1.22OR25M/R0II
4 100 100 34 3.00±0.30 1.00±0.20 1.22OR25M/Roll
5 125 125 42 3.00±0.30 1.00±0.20 1.22OR25M/Roll

Technical Data

I Property Test Method Standard I
Tensile Strength(MPa) ASTM D2671 >10.4
Elongation(%) ASTM D2671 >300
Tensile Strength after aging (MPa) UI224 158°CX168hr N7.3
Elongation after aging(%) UI224 158°CX168hr 3200
Flammability ASTM D2671B Self-extinguish within 30s
Dieletric strength(kV/mm) IEC 60243 >15
Volume resistivity(Q.cm) IEC 60093 ^1X1014

Adhesive

Property Test Method Standard I
Water Absorption ASTM D570 <0.5
Sofening Point(°C) ASTM E28 90±5
Strength of pearing(PE) ASTM D 1000 120N/25mm
Strength of pearing(AL) ASTM D 1000 80N/25mm
