Large Machined Alloy Steel Forgings Shaft Sleeve 4140 4330 18CrNiMo7-6 4340
Large Machined Alloy Steel Forgings Shaft Sleeve 4140 4330 18CrNiMo7-6 4340
Large Machined Alloy Steel Forgings Shaft Sleeve 4140 4330 18CrNiMo7-6 4340
Large Machined Alloy Steel Forgings Shaft Sleeve 4140 4330 18CrNiMo7-6 4340
Large Machined Alloy Steel Forgings Shaft Sleeve 4140 4330 18CrNiMo7-6 4340
Large Machined Alloy Steel Forgings Shaft Sleeve 4140 4330 18CrNiMo7-6 4340
Large Machined Alloy Steel Forgings Shaft Sleeve 4140 4330 18CrNiMo7-6 4340
Large Machined Alloy Steel Forgings Shaft Sleeve 4140 4330 18CrNiMo7-6 4340
Large Machined Alloy Steel Forgings Shaft Sleeve 4140 4330 18CrNiMo7-6 4340
Large Machined Alloy Steel Forgings Shaft Sleeve 4140 4330 18CrNiMo7-6 4340
Specifications
Brand Name :
HUIXUAN
Model Number :
4140，4330，18CrNiMo7-6,4340
Certification :
ASTM，ASME，DIN，JIS，ISO，BS，API，EN
Place of Origin :
China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
2000-5000Ton/month
Delivery Time :
30-50Days
Packaging Details :
Plywood case,Wooden pallet,Steel frame
Material :
Steel
Heating treatment :
N+T Q+T
Forging ratio :
≥4
MOQ :
1PC
Molding Style :
Forging
Max Length :
6000MM
Delivery time :
30-50Days
Melting proce :
EF+LF+VD
Description

Large Machined Alloy Steel Forgings Shaft Sleeve 4140 4330 18CrNiMo7-6 4340​

Products:

Alloy steel sleeve,roll shaft,roll shell

Pipe sleeve,shaft sleeve of mining machinery has advantages as follows,low weight,good mechanical property,long length,easy to weld.

Products reference:

Material 4140,4330,18CrNiMo7-6,4340
Foring equipment 4000T open die hydropress
Application

Large scale mining equipment parts
Melting process EF+LF+VD
Production process

Forging+heat treatment+rough machining+QT
Forging ratio ≥4
Applicable standard ASTM,ASME,DIN,JIS,ISO,BS,API,EN
Executive standard JB/GB/EN/DIN/JIS/ASME/ASTM/ISO
Certification authority ISO9001:2008,BV,SGS,IST,UL.CTI
Delivery term

Rough machining(N+T);QT

Test equipment

Spectrograph,UT device,tensile and compact test machine,metalloscope,outside micrometer,bore dial indicator,hardness test machine
Service Our service included the forging, process, heat treatment, finish machining, package, local logistics, customers clearance and maritime transport. We took the customer’s requirements as the principal thing, and pay attention on the products quality.

Custom properties

Material elements

 C Si Mn P S Cr Ni Mo Others
4140 0.38-0.43 0.15-0.35 0.60-0.90 ≤0.035 ≤0.040 0.80-1.10 -- 0.15-0.25 -
4330 0.28-0.33 0.10-0.35 0.85-1.15 ≤0.020 ≤0.020 0.80-1.10 1.10-1.40 0.35-0.55 -
18CrNiMo7-6 0.15-0.21 0.17-0.35 0.50-0.90 ≤0.025 ≤0.025 1.50-1.80 1.40-1.70 0.25-0.35
4340 0.38-0.43 0.15-0.35 0.60-0.80 ≤0.035 ≤0.040 0.70-0.90 1.65-2.00 0.20-0.30 -

Mechanical property

Dia.(mm)

TS/Rm(Mpa)

YS/Rp0.2(Mpa)

EL/A5(%)

RA/Z(%)

Type Of notch

Impact energy

HBW
4140 Ø15 740~1000 450~850 ≥12 ≥25 V ≥40 ≤250HBS
4330 Ø10 ≥1000 ≥740 ≥12 ≥25 V ≥42 --
18CrNiMo7-6 Ø15 ≥980 ≥785 ≥9 ≥40 V ≥47 ≤269HBS
4340 Ø15 ≥980 ≥835 ≥12 ≥55 V ≥78 ≤179HBS

Commerce clause

Max length 6000MM
MOQ 1PC
Delivery time 30-50 Days
Package Polywood pallet,steel frame
Delivery term FOB;CIF;CFR；DDU；
Payment term T/T,LC
Type of shipping

By ocean,air

Process procedure:

Forging process flow quality control:

  1. Raw material steel ingot into warehouse(test the chemical content)
  2. Cutting→ Heating(Furnace temperture test)
  3. Heat treatment after forging(Furnace temperture test) Discharge the furnace(blank inspection)
  4. Machining→ Inspection(UT,MT,Visal diamention, hardness)
  5. QT→ Inspection(UT, mechanical properties, hardness, grain size)
  6. Finish machining→ Inspection (dimension)
  7. Packing and Marking(steel stamp, mark)→ Storage Shipment

Why choose HUIXUAN?

  • HUIXUAN is a directly professional manufacturer with over 10 years experiences specialized in producing custom forging machining parts.
  • The company is able to meet your high quality standard, performs 100% QC test, certification:ISO9001-2008.
  • HUIXUAN specializes in all kinds of material , surface treatment and heating treatment. Fast & flexible turnaroun,100% on-time delivery.
  • HUIXUAN only takes reasonable profit , competitive price will be our greatest advantage.
  • Our service included the forging, process, heat treatment, finish machining, package, local logistics, customers clearance and maritime transport. We took the customer’s requirements as the principal thing, and pay attention on the products quality.
