Specifications
Brand Name :
HUIXUAN
Model Number :
Formed forging
Certification :
ISO，BV,SGS, IST, UL，CTI
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
3000-5000T/Month
Delivery Time :
10-60 days
Packaging Details :
Wood pallet, steel frame support
Forging equipment :
6000T open die hydropress
Max length :
5000mm
Melting process :
EF+LF+VD
Application :
Machinery parts
Forging ratio :
≥4
Heat treatment :
N+T Q+T
Description

Rectangle Forging Transmission Spline 34CrNiMo6 17CrNiMo6 GSG Certification

Products:

spline forging, transmission spline, rectangle forging, mine spline.

Products reference:

Material

4330,34CrNiMo6,17CrNiMo6,4340

Forging equipment

6000T open die hydropress

Apply for

Transmission spline is used for mine machinery and metallurgical machinery in the function of transmission.

Melting process

EF+LF+VD

Process technology

Forging+heat treatment+rough machining+finish machining

Forging ratio

≥4

Applicable standard

ASTM, ASME, DIN, JIS, ISO, BS, API, EN

Executive standard

 JB/GB/EN/DIN/JIS/ASME/ASTM/ISO

Certification authority

 ISO,BV,SGS, IST, UL,CTI

Verification

Self-inspection or 3rd party withness. All the tested items inspected and qualified before shipment.

Delivery terms

Rough machining(N+T); finish machining(Q+T)

Test equipment

Spectrograph, UT device, tensile and impact test machine, metalloscope,external micrometer, bore dial indicator, hardness testing device and so on.

Service

Our service included the forging, process, heat treatment, finish machining, package, local logistics, customers clearance and maritime transport. We took the customer’s requirements as the principal thing, and pay attention on the products quality.

Custom properties

Material elements

 C Si Mn P S Cr Ni Mo

Others
4330 0.28-0.33 0.10-0.35 0.85-1.15 ≤0.020 ≤0.020 0.80-1.10 1.10-1.40 0.35-0.55 -
34CrNiMo6 0.30-0.38 ≤0.040 0.50-0.80 ≤0.035 ≤0.035 1.30-1.70 1.30-1.70 0.15-0.30
17CrNiMo6 0.15-0.21 0.17-0.35 0.50-0.90 ≤0.025 ≤0.025 1.50-1.80 1.40-1.70 0.25-0.35
4340 0.38-0.43 0.15-0.35 0.60-0.80 ≤0.035 ≤0.040 0.70-0.90 1.65-2.00 0.20-0.30 -

Mechainal properties

Dia.(mm)

TS/Rm(Mpa)

YS/Rp0.2(Mpa)

EL/A5(%)

RA/Z(%)

Type Of notch

Impact energy

HBW
4330 Ø10 ≥1000 ≥740 ≥12 ≥25 V ≥42 --
34CrNiMo6 Ø15 750-900 450-600 ≥13 ≥55 V -40℃≥20 ≤269HBS
17CrNiMo6 Ø15 ≥980 ≥785 ≥9 ≥40 V ≥47 ≤269HBS
4340 Ø15 ≥980 ≥835 ≥12 ≥55 V ≥78 ≤179HBS
Process procedure:

Forging process flow quality control: Raw material steel ingot into warehouse(test the chemical content) → Cutting→ Heating(Furnace temperture test) → Heat treatment after forging(Furnace temperture test) Discharge the furnace(blank inspection)→ Machining→ Inspection(UT,MT,Visal diamention, hardness)→ QT→ Inspection(UT, mechanical properties, hardness, grain size)→ Finish machining→ Inspection (dimension)→ Packing and Marking(steel stamp, mark)→ Storage Shipment

Commerce clause

MOQ 1PC
Max. length 5000MM

Delivery time

10-60 days

Package

Wood pallet, steel frame support

Delivery terms

FOB;CIF;CFR；DDU；

Payment terms

T/T,LC

Type of shipping

By ocean, air

Keywords

Rectangular strip forging, can be welded and process as irregular rack gear products.

Note:

  1. Excellent mechanical properties;
  2. Produce different dimension based on customer’s requirements;
  3. Advanced manufacture equipments and inspection devices;
  4. Excellent technical personality;
  5. Control the production procedure strictly;
