Specifications
Brand Name :
HUIXUAN
Model Number :
Driving shaft
Certification :
ISO,BV,SGS,IST,UL.CTI,CNAS
Place of Origin :
China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
2000-5000 Ton/Month
Delivery Time :
60 days
Packaging Details :
wood pallet,steel frame
Forging ratio :
≥3
Surface :
Polished
Foring equipment :
8000T open die hydropress
Material :
Alloy steel
Oe no. :
OEM
Size :
as customer's demand
Type :
Driveshaft
Quality :
100%tested
Description

Driving shaft with drilled flange Forged alloy steel 4340 Q+T Third party full inspection

Chemical elements analysis identification:
C:0.39
Si:0.20
Mn:0.71
S:0.002
P:0.002
Cr:0.78
Mo:0.22
Ni:1.70


Mechanical property

4340 Tensile strength Mpa Yield strength Mpa Elongation section shrinkage Impact(20℃) Hardness
Analysis Identification 850-1000 ≥665 ≥ 13% ≥50% ≥35 J 248 - 302 HB

Products:
It is used as important conditioning and conditioning parts requiring good toughness, high strength and large size, such as heavy-duty machinery high-load shaft, turbine shaft with diameter greater than 250mm, rotor shaft of helicopter, turbojet engine turbo shaft, blade, high-load transmission parts, crankshaft fasteners. Gear, etc.; It can also be used to operate the rotor shaft and blade above 400℃; It can also be used to make important parts with special performance requirements after nitriding treatment, and can be used as ultra-high strength steel after low temperature tempering or isothermal quenching.

Supplied drawing:
Driving Shaft With Drilled Flange Forged Alloy Steel 8000T Open Die Hydropress

Product details:
An irregular drive shaft with a regular drilled flange
Driving Shaft With Drilled Flange Forged Alloy Steel 8000T Open Die Hydropress

Dimensional measurement:
The figure below is measured using a micrometer.
Driving Shaft With Drilled Flange Forged Alloy Steel 8000T Open Die Hydropress

Features:

High-precision dimensional tolerance;
Excellent mechanical properties;
Produce different dimension based on customer’s requirements;
Advanced manufacture equipments and inspection devices;
Excellent technical personality;
Control the production procedure strictly;
Pay attention on the package protection;

Quality full service.
