HE -006 Quick Lock Terminal Heavy Duty Rectangular Connectors Replace Phoenix Connector
HE -006 Quick Lock Terminal Heavy Duty Rectangular Connectors Replace Phoenix Connector
HE -006 Quick Lock Terminal Heavy Duty Rectangular Connectors Replace Phoenix Connector
HE -006 Quick Lock Terminal Heavy Duty Rectangular Connectors Replace Phoenix Connector
HE -006 Quick Lock Terminal Heavy Duty Rectangular Connectors Replace Phoenix Connector
HE -006 Quick Lock Terminal Heavy Duty Rectangular Connectors Replace Phoenix Connector
Specifications
Brand Name :
ZJHK
Model Number :
HE-006-FZ
Certification :
CE, RoHS, SGS, CQC,
Place of Origin :
China
MOQ :
5
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, Paypal
Supply Ability :
100,000 pcs per month
Delivery Time :
7 Days
Packaging Details :
Standard Export Cartons
Order Number :
09330062901
Model Type: :
Standard Connector HE Series
Material :
Polycarbonate Sabic 3412 ECR
Wire Connection :
Quick Lock
Housing :
H6B Series
Nos of Contact :
6
Description

ZJHK HE-006-FZ


Inserts, Quck Lock termination, Female, Polycarbonate, Rated current: 16A, Size: 6 B, Contacts: 6, Conductor cross-section: 0.14 ... 2.5mm²,


ABB ROBOT BEST CHOICE


Technical data

Version
Termination method Quck Lock termination
Gender Female
Size 6B
With wire protection Yes
Number of contacts 6
PE contact Yes
Technical characteristics
Conductor cross-section 0.14 ... 2.5 mm²
Conductor cross-section AWG 26 ... AWG 14
Rated current 16A
Rated voltage 500 V
Rated impulse voltage 6 kV
Rated voltage acc. to UL 600 V
Rated voltage acc. to CSA 600 V
Insulation resistance > 1010 Ω
Contact resistance ≤ 1 mΩ
Limiting temperature -40 ... +125 °C
Stripping length 7 ... 9 mm
Tightening torque 0.5 Nm
Mating cycles ≥ 500
Material properties
Material (insert) Polycarbonate
Colour (insert) RAL 7032 (pebble grey)
Material (contacts) Copper alloy
Surface (contacts) Silver plated
RoHS compliant with exemption
Commercial data
Packaging size 1
Net weight 60g
Country of origin China
eCl@ss Contact insert for industrial connectors


HE -006 Quick Lock Terminal Heavy Duty Rectangular Connectors Replace Phoenix Connector

HE -006 Quick Lock Terminal Heavy Duty Rectangular Connectors Replace Phoenix Connector
