HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck
HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck
HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck
HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck
HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck
HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck
HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck
HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck
HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck
HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck
HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck
HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck
Specifications
Brand Name :
SINOTRUK HOWO
Model Number :
ZZ3257N3847A
Certification :
CCC
Place of Origin :
China
MOQ :
1unit
Price :
USD18,000-38,000/unit
Payment Terms :
30%TT as deposit, the balance should be paid before delivery; 100% irrevocable confirmed L/C at sight
Supply Ability :
3000units/month
Delivery Time :
30-45 days
Packaging Details :
Nude packing after painted wax
color :
red,yellow,green,white,blue,black,others are optional
driver seat :
air seat
drive side :
left hand drive and right hand drive is optional
Usage :
for road, building and bridge's construction project or mining work
Material :
carbon steel
Engine :
371hp
Gearbox :
HW19710
Drive axle :
HC16,16tons drum brake axle
Description

HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck

1. 10wheelers tipper specifications

Overall Dimension 8600×2496×3450(mm) (L*W*H)
Payload 25000kg Curb Weight 12130kg
Front Overhang 1500mm Rear Overhang 1670mm
Wheelbase 3825mm +1350mm
CHASSIS
Chassis Brand SINOTRUK HOWO
Driving Type 6x4
Cab

HW70/76, left/right hand drive, air-conditioner, single/double bed, up/down and front/back adjustable steering wheel,new European style whole heating and ventilating system, with electronic controlled model,with four points suspension & absorber and stabilizer equipment, all the truck with the double-locking safety belts and outside sun visor
Engine and Power

Brand: SINOTRUK, diesel engine, WD615.69,WD615.62,WD615.87,WD615.47, 4-stroke direct injection,

6-cylinder in-line with water cooling, turbo-charging and inter-cooling, Euro II,EuroIII, Euro IV,EuroV,emission standard
Steering ZF8198, hydraulic steering with power assistance
Transmission HW19710, 10 forward speeds and 2 reverse
Clutch Model: 430, diaphragm clutch
Front Axle HF9, load capacity 9 ton, drum brake
Rear Axle HC16 tandem axle, casting axle housing, double reduction(central reduction+wheel reduction),load capacity 13000kg x2, ratio 5.73 5.45 4.77
Tire 11.00-20,11.00R20,12.00-20,12.00R20.11units including 1 spare tire
CARGO BODY
Inside Dimension 5400/5600/5800mm*2300mm*1500mm(L*W*H)
Hydraulic Cylinder Ventral T-type lift system,front tipping is optional
Steel sheet thickness Floor 8mm, side 6mm
Tailgate One-piece tailgate with upper articulation, safety lock system

2. 1-40 Tons Dump Truck
<10tons HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck

Driving Model:4x2

Engine:65hp,90hp,110hp,115hp,130hp,160hp

Gearbox: Manuel Transmission

Tire:8.25,9.0,10.0

Hydraulic System:Middle lift or Front lift

payload:3-15t
15tons to 25tons HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck

Cabin:L2000, Long Cab,with one bed

Engine: 266hp,290hp,336hp

Gearbox:Manual Transmission with 10 forwards and 2 reverses

Tire:1200R20 Radial tire, 12R22.11Tubless tire

Hydraulic System:Middle lift or front lift

Box Length:4.8-5.4m
25tons to 40tons HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck

Cabin: A7-W one sleeper

Engine: 266hp,290hp,336hp,371hp

Gearbox: Manual Transmission with 10 forwards and 2 reverses

Tire:1200R20 Radial tire, 12R22.11Tubless tire

Hydraulic System:Middle lift or front lift

Box Length:4.8-5.6m

3. How can we choose truck body?
Transport medium Floor(mm) Side(mm)
Soil or Stone 8 4
Construction Waste 10 6
Big Ore 12 8
Coal 6 4
clay 8 4
Grain or Chemical fertilizer 6 4

HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump TruckHOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck

4. Truck and parts warehouse

HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck

HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck

HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck

5. Trucks we exported to South America, Africa and Southeast Asia

HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck

HOWO 371hp 20 Ton 30Tons 20 Cubic Meters 10 Wheeler Heavy Duty Dump Truck
