Large Capacity 40KWh (48V 800AH) LiFePO4 Battery Bank For Solar Power Storage
Large Capacity 40KWh (48V 800AH) LiFePO4 Battery Bank For Solar Power Storage
Large Capacity 40KWh (48V 800AH) LiFePO4 Battery Bank For Solar Power Storage
Large Capacity 40KWh (48V 800AH) LiFePO4 Battery Bank For Solar Power Storage
Specifications
Place of Origin :
China
Brand Name :
HECO
Certification :
MSDS,UN38.3, CE, IEC
Model Number :
PowerRack LV4 8P
MOQ :
1 piece
Price :
Negotiable
Packaging Details :
1 module / wooden case + 1 rack cabinet / wooden case
Delivery Time :
Sample: within 15 days; bulk order:25~60 days, based on the order quantity
Payment Terms :
T/T (30% advance payment, 70% balance payment to deliver the goods), Western Union, Paypal
Supply Ability :
2000 packs/ month
Nominal Voltage :
51.2V
Nominal Capacity :
800Ah
Energy :
40.96KWh
Dimensions :
601*510*1392 mm (23.7*20.1*54.8 inch)
Weight :
433kg
Use :
Solar Energy Storage
Feature :
large capacity, easy installation, maintenance free
Description


Overview
With traditonal energy oil becoming more and more expensive, and the carton emission is turning to be a serious problem that all human beings have to face up with, the use of new energy solar, wind, etc is getting more and more popular. Solar PV industry is growing rapidly under the support of governments all over the world. But solar energy is not stable. It requires energy storage to make it more stable when using. Electrochemical energy storage is one of popular energy storage ways to store solar energy.

HECO is developing high eco lithium-ion energy storage batteries with lighter, longer cycle life to meet the demand of home use energy storage.
HECO 48V standard lithium ion batteries for home energy storage of excellent safety, long cycle life, compact size, elegant outlook, and quite intelligent is very reliable products for households.


Description:
The PowerRack series is composed of 8pcs/10pcs/12pcs 51.2V 100AH modules in parallel or in series and smart BMS. The capacities are from 40kwh to 60kwh. There are Low Voltage(LV) version and High Voltage (LV) version.


Specifications:

Item Parameters
Model Number PowerRack LV4 8P PowerRack LV4 10P PowerRack LV4 12P
Battery Type LiFePO4
Nominal Voltage 48V
Nominal Capacity 800Ah 1000Ah 1200Ah
Nominal Energy 41kWh 51kWh 61kWh
Cycle Life 3500 Cycles

Size

(W*D*H)

 601*510*1392mm (23.7*20.1*54.8 inch) 601*510*1756mm (23.7*20.1*69.2 inch)

601*510*2120mm

(23.7*20.1*83.5 inch)
Weight 433kg (954.6 lbs) 644kg (1419.8 lbs)
Protection Level IP20
Certification CE/IEC 62619/IEC 62040/UN38.3
Compatible Inverters Victron/SMA/Goodwe/Imeon/Solis/SAJ/Growatt/Luxpower/Voltronic/Deye etc
OEM/ODM Yes (Accepted)
Warranty 5 Years
