20AH / 24V LiFePO4 Lithium Battery Pack For Solar System , 60℃
20AH / 24V LiFePO4 Lithium Battery Pack For Solar System , 60℃
Specifications
Brand Name :
HECO
Model Number :
HK-SL-24F20-B
Certification :
CE,RoHS ,UN38.3, ISO
Place of Origin :
China
MOQ :
10 Packs
Price :
Negotiable
Payment Terms :
T/T (30% advance payment, 70% balance payment to deliver the goods);Western Union, Paypal
Supply Ability :
5000 packs/ month
Delivery Time :
Sample: within 15 days;bulk order:25~60 days, based on the order quantity
Packaging Details :
1 packs/carton, carton size: 570*240*230mm
Nominal voltage :
24V
Nominal capacity :
20AH
Weight :
4kg
Dimenisons :
200*168*160mm
Application :
Solar system, electric scooter, electric wheelchair
Rated discharging current :
10A
Description

20AH / 24V LiFePO4 Lithium Battery Pack For Solar System , 60℃

Quick Detail:

1. Soft-pack LiFePO4 cells inside
2. Compact in size and light in weight

3. BMS manages to each cell for high reliability
4. Extra long cycle life - 5 times life of Lead Acid and 2 times of NiMH
5. Extremely safe: No explosion, no fire under collision, over charged or short circuit

Description:

20AH / 24V LiFePO4 Lithium Battery Pack For Solar System , 60℃

Compared with the same capacity lead-acid battery, LiFePO4 battery is 1/3 smaller in size, 2/3 lighter in weight, 5 times longer in cycle life, more economic and eco-friendly.

LiFePO4 battery replacing Lead acid battery is an inevitable trend.

Compared with same capacity Li-NixCoyMnz battery, LiFePO4 battery is 2.5 times longer in cycle life, also most the same in weight & size.

Basic knowledge:

Lithium ion battery, classified by the anode material, can be divided into li-MH,Li-Co2, Li-NixCoyMnz, and Li-FePO4, etc.

Classified by the battery shell, can be divided into plastic shell, stell/iron shell and aluminum shell.

All these lithium ion batteries have their own advantages. The technical data of their comparative performances is as follows:

Different Lithium Battery Material Comparision Table

NO.

Parameters

Li-Co2

Li-NiCoMn

Li-MnO2

LiFePO4

1

Energy density (g/cm3)

2.8~3.0

2.0~2.3

2.2~2.4

1.0~1.4

2

Specific area (m2/g)

0.4~0.6

0.2~0.4

0.4~0.8

12~20

3

Capacity density (Ah/kg)

135~140

155~165

100~115

130~140

4

Voltage

3.7

3.6

3.6

3.2

5

Cycle life

＞300

＞800

＞500

＞2000

6

Transition metal

Poor

Poor

Rich

Very rich

7

Material cost

Very high

High

Cheap

Cheap

8

Environmental performance

Contain Co

Contain Co & Ni

Non-toxic

Non-toxic

9

Safety performance

Bad

Good

Better

Excellent

10

Application area

Small battery

Small battery Small power battery

Power battery

Power battery Large capacity power supply

Specifications:

Item

Description

Nominal Voltage

24V

Rated Capacity

20Ah

Pack Dimension

 200*168*160mm

Internal Impedance

≤100mΩ

Charging Mode

CC/CV

Pack weight

About 4kg
Rated Discharging current 10A
Peak discharging current 20A
Rated charging current 4A

Over Current Protection

YES

Cycle Life

At least 1200 Cycles @ 100%DOD

Charge Temperature

0-60 ℃

Discharge Temperature

-20-60 ℃

The data on the table is only for reference

20AH / 24V LiFePO4 Lithium Battery Pack For Solar System , 60℃

Company advantages:

1. Advanced polymer lithium-ion battery technology system ensure the correct technical direction and advanced leading technology
2. Excellent procedure quality tracking control system ensure HECO battery’s excellent performance and good consistency.
3. One-stop lithium battery system solutions. Heco’s research and development team include electronic engineer, mechanical engineer, structure engineer, whom could offer our clients one stop solutions including BMS, charger, battery pack structure, and overall applications.
4. Intimate and in time reacting service system. We always try to offer more than expected, do more than required.

Tag: 24V lifepo4 battery, 24V 20AH lithium battery, 24V solar system lithium battery
