3.2V 230Ah Prismatic Aluminium Case LiFePO4 Battery Cell 1C Discharge Rate
3.2V 230Ah Prismatic Aluminium Case LiFePO4 Battery Cell 1C Discharge Rate
Specifications
Brand Name :
HECO
Model Number :
IFP
Certification :
MSDS, UN38.3, IEC62619, CE, UL,BIS
Place of Origin :
China
MOQ :
100pcs
Price :
Negociable
Payment Terms :
T/T (30% advance payment, 70% balance payment to deliver the goods), , L/C
Supply Ability :
10000 pcs/ day
Delivery Time :
Sample: within 3 working days, bulk order:10~20 days
Packaging Details :
4ps/carton
Voltage :
3.2V
Capacity :
230Ah
Dimensions :
53.72*173.9*204.6mm
Weight :
4.2kg
Charge rate :
1C
Discharge rate :
1C
Cycle life :
3000 cycles (1C charge/discharge @25℃)
Description


Features:
1- orignal with laser welding terminal, also can be turned to bolt terminal
2- low resistance which is 30% higher heat dissipation efficiency compared with peers
3- Extra long cycle life: more than 3000 cycles under 1C charge/discharge rate @ 25℃

4- full certifications including UN38.3, IEC62619, CB, UL, BIS certificates ensure the cell can enter every market over the world

Parameters:

Certificates:

Packaging:



Full Prismatic Cell Models List:

Model No. Nominal Voltage Nominal Capacity Resistance Coninuous Discharge Current Discharge Cut-off Voltage Charge Current Charge Cut-off Voltage Dimensions (MAX) Approx Weight Cycle Life
V Ah mΩ A V A V mm(T*W*L) kg
L148F72 3.2 72 ≤1C 3.65
L148F88 3.2 88 2C 3.65 52*148*105
L194F54 3.2 54 4C 3.65 30*194*87
L194F130 3.2 130 ≤1C 3.65 51*194*113
L160F100 3.2 100 ≤1C 3.65 50*160*118
L173F125 3.2 125 ≤1C 3.65 36*173*180
L173F163 3.2 163 ≤1C 3.65 36*173*220
L173F230 3.2 230 ≤1C 3.65 54*173*207

L173F280 3.2 280 ≤1C 3.65 71*173*205

≥7000
(0.2C charge /

0.5C discharge

@ 25℃)
L173F314 3.2 314 ≤1C 3.65 ≥12000

(0.2C charge /

0.5C discharge

@ 25℃)




Company advantages:


1. Advanced LiFePO4 battery technology system ensure the correct technical direction and advanced leading technology.
2. Excellent procedure quality tracking control system ensure HECO battery’s excellent performance and good consistency.
3. One-stop lithium battery system solutions. Heco’s research and development team include electronic engineer, mechanical engineer, structure engineer, whom could offer our clients one stop solutions including BMS, charger, battery pack structure, and overall applications.
4. Intimate and in time reacting service system. We always try to offer more than expected and do more than required.


Tag: 200ah LiFePO4 battery cell, 200ah LFP cell, 3.2V 200AH LFP cell
