Recirculator for self-service Atm cash receiver ATM Cash Machine
Specification
Independent developed cash module:
Adopted 10 categories banknote recognition technologies and scalable for foreign currency recognition, the independent developed high performance cash module is designed with higher security.
Ultra-fast banknote handling speed:
Banknote handling speed is up to 10 notes per second, and banknotes with different denominations can be processed in bunch.
Support forgotten banknote retract:
Customer forgotten banknotes can be retracted automatically, avoiding accounting disputes and ensuring the security of customer money.
Flexible and scalable:
With reserved scalable space, bank business can be enriched with optional functions such as biometrics recognition, optoelectronic identification, mobile phone transactions, bill payment and coin deposit/withdrawal.
Comprehensive security measures:
Anti-glare screen with privacy filter, vandal-resistant damage, waterproof, anti-skimming, intelligent detection, to keep the security of cash and data.
Components | Details | |
PC system | Industrial Board | Seavo/ Gigabyte/Advantech AIMB 562 |
CPU | Dual core E5700/G2020, 2.8ghz; Intel Dual Core I3/I5/I7 | |
RAM | 2GB /4 GB / 8GB | |
HDD | 500G | |
Interface | 6 RS-232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card | |
PC Power Supply | HUNTKEY/Great Wall | |
LCD monitor | Screen Size | 17 inch/19inch ( optional from 8inch to 65inch) |
Brightness | 250cd/m2 | |
angle | horizontal 100°above;Vertical 80°above | |
Contrast | 1000:1 | |
Backlight tube life | more than 40,000hours | |
Max. resolution | 1280×1024 | |
Touch screen | Screen Size | 17/19 inch Diagonal ( optional from 8inch to 65inch) |
Resolution | 4096x4096 | |
High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times | ||
Bank/Credit Card Reader | Interface | RS232 |
Card Type | Support Magcard, IC Card, RF Card, Mifare S50,S70,UL Card | |
Power Voltage | DC 24V±5% | |
Card Entry method | Magnetic signal, Optoelectronic signal and rear card signal | |
Encrypted Pinpad | Keylift~span | 2,000,000 cycles |
Key force | 2~3N | |
Key trip | >2.5mm | |
Protection level | ip65 | |
Cashcode Bill acceptor | Validation Rate | 96% or higher |
Banknote Insertion | Four-way | |
Escrow | One banknote | |
Capacity | 1000 notes Max | |
Coin Acceptor | Coin Acceptance | Max 32 coin types, in 2*16 or 1*32 channels |
Detection ability of counterfeit Coins | with high detection ability of counterfeit coins | |
Accepting Speed | 2 Coins/Sec | |
Supply Voltage | 10V-16V DC | |
Epson receipt thermal printer | Autocutter | included |
Technology | Thermal printing | |
Paper width | 80mm | |
Printing speed | 150mm/s | |
Data buffer | 4KB | |
Interface | RS232 ,USB | |
UPS | Input voltage | 145-290va |
Output voltage | 200-255va | |
Max time for supplying a single PC | 3~20minutes (for single PC) | |
Digital Power Supply | AC input voltage range | 100~240VAC |
Frequency | 50Hz to 60Hz | |
AC input voltage range | 100~240VAC | |
Frequency | 50Hz to 60Hz | |
Accessories | Wire-lan port, USB ports, speakers, fans, cables, screws, etc. | |
Operation System | Windows 7 or Windows XP operation system without license | |
KIOSK Cabinet | Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request. | |
Packing | Security Packing method with bubble foam and wooden case |
If you are interested in our kiosks, please inform us your detail requirements as below or any other related, so we can quote accurately.
If you order from us, you will get these advantages:
FAQ
1. Are you a manufacturer?
Yes, we are a professional ATM and ATM hardware manufacturer, headquartered in Dongguan, China.
2. Can I get some samples? Are they free?
Of course, you can get sample for testing before bulk order, but samples are not free.
3. What are your payment terms?
We accept T/T,Trade Assurance Order or Paypal payment terms.You can choose the payment terms which convenient to you.
4. What about the warranty time?
We provide 1 year warranty for all our product .
5. Can I have my own logo on the products, do you offer product OEM?
Yes! We can put your logo on the product and we do OEM for customers. But it requires a certain quantity and the cost need to be added separately.
6. What kind of certificate you have?
CE, FCC and RoHS as standard.Some products approved EMv&PCI,CB,CCC certificates.
7. What about the after-sale service?
We provide full technical support on our products, if there is a machine doesn’t work,a free parts will be sent to you by free to replace,if it still not working, we will send you a new one.
