14 Ton Hydraulic Double Drum Vibratory Road Roller LTC214 for Sale
14 Ton Hydraulic Double Drum Vibratory Road Roller LTC214 for Sale
14 Ton Hydraulic Double Drum Vibratory Road Roller LTC214 for Sale
14 Ton Hydraulic Double Drum Vibratory Road Roller LTC214 for Sale
14 Ton Hydraulic Double Drum Vibratory Road Roller LTC214 for Sale
14 Ton Hydraulic Double Drum Vibratory Road Roller LTC214 for Sale
14 Ton Hydraulic Double Drum Vibratory Road Roller LTC214 for Sale
14 Ton Hydraulic Double Drum Vibratory Road Roller LTC214 for Sale
Specifications
Model Number :
LTC14
Certification :
CE/ISO9001
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1000 units per month
Delivery Time :
10-15 working days
Packaging Details :
nude
Operating mass :
14000kg
Engine :
Cummins
Power :
110kW
Drum width :
2100mm
Dimension :
5060 x 2250 x 3300 mm
Warranty :
1 Year
Description

LTC214 hydraulic vibratory rollers are manufactured according to international advanced technology and using
imported components from abroad. The machine is a double drums tandem vibratory roller. It is primarily used for
the compaction of road bituminous course, sand gravel mixtures and RCC material. Being a universal compaction
equipment for highway, municipal road, park area and industry ground etc.

►Full hydraulic two wheels drive and vibration. Double frequency double vibration system;
Reliable CUMMINS diesel engine for convenient operation and maintenance;
Hydrostatic center articulated steering (optional patented crab mechanism);
Cabin is comfortable and spacious with air conditioner, and the flexible steering seat facilitate the operation;
The driver's cabin can be turned on one side as a whole, to facilitate maintenance;
For-type frame, good hold-down property;
Hydraulic plunger pump and motors are made by American manufacturer DANFOSS
14 Ton Hydraulic Double Drum Vibratory Road Roller LTC214 for Sale

Main Technical Parameters:
Model LTC214
Operating mass 14000kg
Font axle load 7000kg
Rear axle load 7000kg
Static linear load 333N/cm
Form of frame fork-type
Type of water spray pressure
Water tank capacity 600x2 L
Fuel tank capacity 154 L
Hydraulic oil tank capacity 65 L
Vibration amplitude 0.8(High)/0.4(Low)mm
Vibration frequency 46(high)/40(low)Hz
Centrifugal force 160x2(high)/90x2(low)Kn
Travel Speed 0-10Km/h
Steering angle ±30°
Electrical voltage 24V
Grade ability 40%
Turning radius 7000mm
Overall dimension (LxWxH) 5060x2250x3300mm
Vibration drum diameter 1350mm
Drum width 2100mm
Wheel base 3717mm
Diesel engine power 110Kw/2300rpm
Diesel engine model 6BT5.9
Ship 1 unit/40HQ
Optional: Edge cutter, Canopy.
