Biochar Charcoal Retort Kiln Machines Pyrolysis Charcoal Retort Kilns On Sale

Pyrolysis Biomass Charcoal Making Machines Product Description:

Continuous pyrolysis carbonization machine is carbonization equipment which can carbonize coconut shell, walnut shell, apricot shell, sawdust, sawdust, rice husk, under high temperature conditions.

The pyrolysis carbonization machine purification and circulating combustion of carbon monoxide, solves the heat energy problem required by the equipment, fully realizes self-sufficiency, we should make full use of the agricultural and forestry residues to turn waste into treasure and contribute to the greening environment.

Pyrolysis Biomass Charcoal Making Machines Working Principle:

Continuous pyrolysis carbonization machine is a professional equipment for continuous high-temperature heating and carbonization of biomass under the condition of no oxygen and poor oxygen. It is composed of two-layer carbonization machine, preheat wood powder burner (or gasifier, natural gas burner), combustible gas purification device, external heating furnace of carbonization machine, feeding conveyor, cooling and carbon discharging machine and control, etc In this paper. The biomass is transported into the inner drum by the conveyor. The waste heat in the furnace is used to dry and preheat the materials to 200-250 ºC.

The outer drum is provided with a combustible gas recovery pipeline at the end. The combustible gases such as carbon monoxide, methane and ethane produced in the carbonization process are fully utilized to separate wood tar, wood acid solution, water and ash through the flue gas purification system The pure combustible gas is sent to the heating furnace outside the carbonization machine for full combustion and heating to the carbonization machine to achieve reciprocating cycle heating and continuous production. The carbonization temperature is generally controlled at / 700-800 ºC.

Pyrolysis Biomass Charcoal Making Machines Device Configuration:

1, flue gas purification, heat exchange system, cooling system, heat steam into water, flue gas can be converted to gas recycling;

2, frequency conversion feeding machine, automatic feeding, feeding speed is adjustable;

3, configuration rotary carbonation host, meet the production requirements;

4, cooling discharging machine cooling products, output, product;

5, the control cabinet, temperature, speed regulation, drum PLC automatic control cabinet.

Pyrolysis Biomass Charcoal Making Machines Advantages:

1. Biomass with water content less than 30% and size less than 30mm can be carbonized;

2. The carbon products can be used not only as fuel carbon, water smoke carbon, but also as raw materials of metallurgical carbon and activated carbon;

3. The pyrolysis depth control ability is strong. The residue of volatile matter in carbon products is 10-25%, which can be controlled on demand;

4.The pyrolysis charcoal machine use patent technology design, precision production, after a large number of practical tests, every detail is pursuit of perfection, to ensure the quality of each set of equipment.

CARBONIZATION REQUIREMENTS

Biomass particles or e-waste with a particle size of less than 50mm and a moisture content of less than 20% can be directly entered into the first-type machine for carbonization.

For example, sawdust, coconut shells, fruit shells, palm shells, etc. can be directly carbonized;

larger (50mm or more) raw materials, such as aluminum capacitors, wires, waste clothes, wood branches, etc.,need to be shredded and then carbonized;

if the moisture exceeds 30%, it needs to be dried in advance.

This product is a customized product, and the display price is for reference only
