1800×1500×2240mm ISO PCB Air Showers 1.53KW With Auto Double Sliding Doors
1800×1500×2240mm ISO PCB Air Showers 1.53KW With Auto Double Sliding Doors
Specifications
Brand Name :
anlaitech
Model Number :
AL-air shower
Certification :
ISO9001,CE
Place of Origin :
CHINA
MOQ :
1set of china clean room
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
12WORKING DAYS.
Packaging Details :
standard exporting packing for clean room china
Name :
1800×1500×2240mm ISO PCB Air Showers 1.53KW With Auto Double Sliding Doors
Material :
stainless steel,cold steel,colored steel sandwich board
Product name :
Cleanroom Air Shower,Air Shower clean room,Color Plate Airshower
Hepa filter :
99.999% efficiency at 0.3 um
Spraying wind speed :
25m/s,≥25 for clean room air shower
Description

1800*1500*2240mm Best Sold Air shower Room with Automatically Double sliding Doors

Air shower is a frequently used equipment in clean room. It removes dust particles on the surface of the goods effectively to so that dusts will not be brought in to the clean room by goods. Meanwhile, air shower works as an air lock which separates clean area and unclean area to keep the pressure in the clean room steady.

Application: Air shower is widely used in LCD and Optoelectronic Display, PCB, microelectronics, dust-free coating, aseptic packaging, medical care, Pharmacy,auto glass and precision parts.

Air shower​ FEATURES:

1,Fully auto controlled by computer, 2 electronic interlocking door, automatically blow and shower.

2,Duration for showering can be adjusted from 0 second to 99 seconds with time display and voice prompt. It is easy to operate with membrane touch switches.

3,Floor and nozzles are made of quality stainless steel.

4,99.99%@0.3μm, Efficiency can reach 99.99%@0.3μm with pre filter and hepa filter.

5,20m/s air velocity can up to 20m/s. professional and fast design, non-standard products.

1800×1500×2240mm ISO PCB Air Showers 1.53KW With Auto Double Sliding Doors

Alternative configuration:

a. Stainless steel construction

b. Intercom

c. Ultraviolet sterilizing lamp/yellow light

d. Buzzer

e. Non-flooring-plate design (easy for light- weight vehicle in and out)

f. Automatic door

g. Non-standard air shower cleanroom is available

AIR SHOWER SPECIFICATIONS:

Model AL-AS-1300/P1 AL-AS-1300/S1 AL-AS-1300/P3
External Size (WxLxHmm) 1300x1000x2180 1300x1500x2180 1300x3000x2180
Internal Size (WxLxHmm) 800x930x1960 800x1430x1960 800x930x1960
Nozzle in stainless steel (pc) 16 24 48
Nozzle wind speed (m/s) ≥25 ≥25 ≥25
Noise (1m away) (dB) <65 <65 <65
Fan Power supply 380/220 380/220 380/220
Power (W/set) 750×2 1100×2 1100×4
Quantity /set 2 4 6
Air flow (m³/h) 2000 2500 5000
HEPA filter Size (W×H×Dmm) 610×610×69 610×610×69 610×610×69
Quantity (set) 2 2 4
Pre-filter Size (W×H×Dmm) 775×380×17 775×380×17 775×380×17
Quantity (set) 2 2 2
Total power supply/W 1530 2260 4520

Anlaitech Air Shower Advantages

1) Customizable
Choose one or more of our 14 optional features to build the perfect air shower for your needs.

2) Modern
anlaitech air showers are manufactured to exacting standards using state-of-the-art machinery including laser cutting and CNC automatic sheet cutting equipment. We use only SUS304-grade stainless steel and high-quality cold-rolled steel plates for our interior and exterior surfaces.

3) Smart
Our air showers come equipped with a 7" LCD touchscreen display PLC system, an OTS error code display system, and available audio prompts and instructions. The system can be set to manual or automatic mode, and includes security features such as a screen lock, delayed light timer, password protection, and total system access control.

4) Dependable
All electrical air shower components, including door locks (LCJ), door seals (Dorma), and LED lights (Omron) employ patented, innovative technologies. All other proprietary technologies are covered in Chinese patent ZL 2010-2 0502252-1.

5) Flexible
We can customize and add features such as UV lights, door configuration, air shower dimensions, interior/exterior materials, ozone generators, infrared sensing technologies, fingerprint access, etc. according to your needs.

1800×1500×2240mm ISO PCB Air Showers 1.53KW With Auto Double Sliding Doors

1800×1500×2240mm ISO PCB Air Showers 1.53KW With Auto Double Sliding Doors

FAQ


Q: Are you manufacturer or trading company?
A: We are manufacturer for clean room equipment, we have plant in Guangzhou

Q: What's your product?
A: We specialty in manufacturing clean room equipment and filters, and then the accessory for clean room
equipment.

Q:How about your after sale service?
A:We will reply you within 24hours by email or phone.
If we have local agent,we will arrange him to your site within 24 hours to assist you to shoot the problem.

Q:Can you arrange the visit to your user?Can you customized the machine according to our requirements?
A:Yes,Of course.
