7500m3/H ISO Class 8 Clean Room Dust Free , 220V 63dB Medical Device Cleanroom
7500m3/H ISO Class 8 Clean Room Dust Free , 220V 63dB Medical Device Cleanroom
7500m3/H ISO Class 8 Clean Room Dust Free , 220V 63dB Medical Device Cleanroom
7500m3/H ISO Class 8 Clean Room Dust Free , 220V 63dB Medical Device Cleanroom
Specifications
Brand Name :
anlaitech
Model Number :
AL-MODULAR CLEAN ROOM
Certification :
CE , FAT, CLASS REPORT
Place of Origin :
CHINA
MOQ :
1set of china clean room
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
12WORKING DAYS.
Packaging Details :
standard exporting packing for clean room china
Name :
7500m3/H ISO Class 8 Clean Room Dust Free , 220V 63dB Medical Device Cleanroom
Material :
Sandwich panel stainless steel /Painted steel+plexiglass
Product Name :
clean room, lab clean room, modular clean room, cleanroom
Application :
lab clean room, optics clean room, electronical clean room,Pharmaceutical clean room..etc
Power supply :
220V/50Hz
Air flow (m3/h) :
7500m3/H
Description

ISO Class 8 Dust free Medical Device Cleanroom workshop and manufacturer

Medical Device Cleanroom sulotions:

(1) It is crucial to maintain a contaminant-free clean environment when manufacturing medical devices such as biological implants. This starts with the cleanroom design and management systems. The cleanroom design prevents outside contamination, while regular maintenance and sanitation upkeep minimize the risk of contamination originating within the cleanroom itself.

(2) Implants that are non-sterile or are awaiting sterilization should be subject to purification and clean packaging processes. This will allow for uniformity and control over product quality. When constructing a GMP Medical Instrument Cleanroom, a location should be designated for the packaging process, and processes should be implemented to ensure that products avoid contamination risk at all times.

(3) Procedures must be developed to control environments in which there exists a contamination risk to products. This includes any time personnel makes contact with a product, including when products are moved from one location to another.

Maximum Particles/m³
≥0.1μm
≥0.2μm
≥0.3μm
≥0.5μm
≥1μm
≥5μm
ISO 3
1,000
237
102
35b
d
CLASS 1
ISO 4
10,000
2370
1,020
352
83b
CLASS 10
ISO 5
100,000
23700
10,200
3,520
832
CLASS 100
ISO 6
1,000,000
237,000
102,000
35,200
8,320
CLASS 1000

Application: E-Cigarette, LCM, CMOS Camera Module, Touch Play, Optical Module, FILM, Biological Pharmacy,

Packing,Food

Main Features
(1) Assembly structure designed, easy installation and easily moved
(2) Directional wheels can be installed, suitable for small building and high cleanliness area;
(3) Modular design: clean booth can be as small as several square meters and can be as large as hundreds of square meters
(4) It has large useful and effective area; while compared with traditional clean room, it has such features like low investment, high return and stable.

7500m3/H ISO Class 8 Clean Room Dust Free , 220V 63dB Medical Device Cleanroom
Specification
Model item
ISO 8 CLEAN ROOM
AL-CS4*6/C8
AL-CS5*10/C8
AL-CS6*12/C8
AL-CS7*20/C8
Size(mm)
4000*6000*2500
5000*10000*2500
6000*12000*2500
7000*20000*2500
Material
Framework
Cold rolled steel /Aluminum/Stainless steel/sandwich panel
Around
Plexiglass,Soft curtain,Anti-static strip curtain/sandwich panel
Clean Class Level
10000
10000
10000
10000
HEPA filter
Size(mm)
610*610*69
1220*610*69
1220*610*69
1220*610*69
Efficiency(%)
99.99
99.99
99.99
99.99
Air flow (m3/h)
3600
7500
10800
21000
Pre filter
Size(mm)
Optional
Motor Spec
Power supply
220V/50Hz
220V/50Hz
220V/50Hz
220V/50Hz
Noise(dB)
62
63
62
63

What We Can Do For You?

Front end consultancy support, Concept design and engineering.

Clean room design and construction.

Unique range of clean room modular walls and ceilings, flooring system.

Cleanroom accessories (pass boxes, step over benches, change room furniture and fittings, sampling and dispensing booths, air showers, etc.) GRP clean room doors.

Equipment selection ,Validation master plans, protocols and continuous monitoring systems regulatory advise.

HVAC Design and Installation.
