62dB 5.0µ Class 1000 Clean Rooms ISO 6 21000m3/H Sandwich Panel
62dB 5.0µ Class 1000 Clean Rooms ISO 6 21000m3/H Sandwich Panel
62dB 5.0µ Class 1000 Clean Rooms ISO 6 21000m3/H Sandwich Panel
62dB 5.0µ Class 1000 Clean Rooms ISO 6 21000m3/H Sandwich Panel
Specifications
Brand Name :
anlaitech
Model Number :
AL-MODULAR CLEAN ROOM
Certification :
CE , FAT, CLASS REPORT
Place of Origin :
CHINA
MOQ :
1set of china clean room
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
12WORKING DAYS.
Packaging Details :
standard exporting packing for clean room china
Name :
62dB 5.0µ Class 1000 Clean Rooms ISO 6 21000m3/H Sandwich Panel
Material :
Sandwich panel stainless steel /Painted steel+plexiglass
Product Name :
clean room, lab clean room, modular clean room, cleanroom
Application :
lab clean room, optics clean room, electronical clean room,Pharmaceutical clean room..etc
Particle Sizes :
5.0µ
Noise(dB) :
62dB, 63dB
Description

ISO 6 or Class 1,000 Cleanrooms

ISO 6 or Class 1,000 Cleanrooms are a high usage classification of cleanrooms across a variety of industries and application types. ISO 6 Cleanrooms are utilized in biotechnology, pharmaceutical, nanotechnology, and various cleantech manufacturing applications such as ion lithium battery, solar, medical device, film / packaging, and fine chemical.

ISO 6 Cleanroom Design Specifications

Model item
ISO 6 CLEAN ROOM
AL-CS4*6/C6
AL-CS5*10/C6
AL-CS6*12/C6
AL-CS7*20/C6
Size(mm)
4000*6000*2500
5000*10000*2500
6000*12000*2500
7000*20000*2500
Material
Framework
Cold rolled steel /Aluminum/Stainless steel/sandwich panel
Around
Plexiglass,Soft curtain,Anti-static strip curtain/sandwich panel
Clean Class Level
10000
10000
10000
10000
HEPA filter
Size(mm)
610*610*69
1220*610*69
1220*610*69
1220*610*69
Efficiency(%)
99.99
99.99
99.99
99.99
Air flow (m3/h)
3600
7500
10800
21000
Pre filter
Size(mm)
Optional
Motor Spec
Power supply
220V/50Hz
220V/50Hz
220V/50Hz
220V/50Hz
Noise(dB)
62
63
62
63

62dB 5.0µ Class 1000 Clean Rooms ISO 6 21000m3/H Sandwich Panel
Filtration & Particle Control
  • Focused measurement of particle sizes greater than 0.5µ and less than 5.0µ
  • High Efficiency Penetration Air (HEPA) Filtration efficiency: 99.99% at 0.3 microns
  • Final filtration is performed at the air entry point of the cleanroom, and is commonly performed by terminal HEPA modules or HEPA FFU (fan filter modules) depending on the application.
  • 35,200 PPC (particles per cubic meter) at 0.5µ
  • Environmental parameters such as temperature, humidity, lighting levels, noise criteria, static control, and outgassing are often driven by the requirements of the specific process being performed in the cleanroom.
