Prefabricated 63dB Plexiglass ISO Class 8 Clean Room , 21000m3/H Portable Clean Rooms
Prefabricated 63dB Plexiglass ISO Class 8 Clean Room , 21000m3/H Portable Clean Rooms
Specifications
Brand Name :
anlaitech
Model Number :
AL-MODULAR CLEAN ROOM
Certification :
CE , FAT, CLASS REPORT
Place of Origin :
CHINA
MOQ :
1set of china clean room
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
12WORKING DAYS.
Packaging Details :
standard exporting packing for clean room china
Material :
Epoxy powder coated steel
Product Name :
potable clean room,prefabricated clean room, Dust free clean room
Condition :
New
Name :
Prefabricated 63dB Plexiglass ISO Class 8 Clean Room , 21000m3/H Portable Clean Rooms
Power supply :
220V/50Hz
Air flow (m3/h) :
21000
Description

Prefabricated ISO Class 8 Clean Room, Portable Clean Rooms

ISO 8 suite for the production of PPE and medical devices with design, certification, installation and air balancing included. Scratch free NICOMAC modular walls, doors, visuals, pharmaceutical-type ceilings with air conditioning system with HEPA filters or FFU’s, and temperature control.
The ISO 8 Suite is a 600 Sq.ft. clean room ready for easy and quick installation, with personnel and materials airlocks. The installation can be performed within 45 days from PO and can be carried out in any building with suitable area.

The quality and reliability are guaranteed by anlaitech., with 20 years of experience and with more than 1,500 installations in China and Worldwide. The system can include a qualification and sanitization system.

Modular clean room Benefit:

modular cleanroom system offers significant financial and performance advantages over traditional cleanroom solutions. Misterium is designed to meet the demands of the most stringent medical and aseptic environments. As a result, it is the solution of choice by many biomed, life science, biotech, medical device, nutraceutical, and pharmaceutical facilities.

Clean room ISO Class and Airflow
The lower your ISO class, the more frequently air needs to pass through the HEPA filter, which is measured in air change per hour (ACH).
A common HVAC airflow will change the air twice or so per hour. However, in a cleanroom setting, the air needs to be cycled at least 10 times per hour.
Air Changes Per Hour (ACH)
ISO Class Approximate air changes per hour needed
ISO 8: 10 to 25
ISO 7: 30 to 50
ISO 6: 60 to 150
ISO 5: 150 to 250+
Next, we use your ACH and the size of each room to calculate required airflow, measured in cubic feet per minute (CFM).

CLEAN ROOM Specification:
Model item
ISO 8 CLEAN ROOM
AL-CS4*6/C8
AL-CS5*10/C8
AL-CS6*12/C8
AL-CS7*20/C8
Size(mm)
4000*6000*2500
5000*10000*2500
6000*12000*2500
7000*20000*2500
Material
Framework
Cold rolled steel /Aluminum/Stainless steel/sandwich panel
Around
Plexiglass,Soft curtain,Anti-static strip curtain/sandwich panel
Clean Class Level
10000
10000
10000
10000
HEPA filter
Size(mm)
610*610*69
1220*610*69
1220*610*69
1220*610*69
Efficiency(%)
99.99
99.99
99.99
99.99
Air flow (m3/h)
3600
7500
10800
21000
Pre filter
Size(mm)
Optional
Motor Spec
Power supply
220V/50Hz
220V/50Hz
220V/50Hz
220V/50Hz
Noise(dB)
62
63
62
63

How do you choose the correct cleanroom to meet your needs?

What are the determining factors that will decide the level of cleanroom you need, or if your operations would be better suited with a controlled environment instead?

The cleanroom you may need is going to be determined by several different factors:

Industry Standards


Government Regulations


Customer Requirements


Ease of Cleaning


Restriction of Access


Particulates


Temperature


Humidity


Microorganism

Once all of these factors are considered, you can then make accurate choices regarding the scope of the cleanroom operation you should implement, or whether your operations would be better suited with a controlled environment instead.
