Portable SUS304 32 Feet Softwall Clean Room , 7500m3/H Class 1000 Clean Room
Portable SUS304 32 Feet Softwall Clean Room , 7500m3/H Class 1000 Clean Room
Specifications
Brand Name :
anlaitech
Model Number :
AL-MODULAR CLEAN ROOM
Certification :
CE , FAT, CLASS REPORT
Place of Origin :
CHINA
MOQ :
1set of china clean room
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
12WORKING DAYS.
Packaging Details :
standard exporting packing for clean room china
After-sales service provided :
Engineers available to service machinery overseas
Material :
Stainless Steel,Stailess Steel SUS304/201/Q195 /galvanized Sheet,color plate for clean room,Customized SUS or Aluminium,customized
Application :
100 Lab / Laboratory Clean Room,OT Room,Clean room,air cleaning in a small area,Chemical Lab
Product name :
Air Clean Room Clean Booth,Class 10000 Clean Room,Softwall clean room,Cleanroom,class 1000 laminar air flow Hardwall Clean Booth
Type :
Clean Room Booth,modular clean room,cleanroom,Modular Designs,Hardwall or Softwall
Cleanliness :
From Class100-10000,From Class 10-10000
Name :
Cleanroom Project,Clean booth,Hospital Clean room,Level Clean Room,Class 1000 Clean Room
Size :
customized,As your request
Description

High Cleanliness Potable Softwall Clean Room, Class 1000 Clean Room

anlaitech offers a complete selection of portable and modular cleanrooms in both hardwall or softwall configurations. These modular cleanrooms are available from class 10 (ISO 4) to class 100,000 (ISO 8). Recirculating air flow systems can be provided for climate control.

Modular Design


The modular design of the cleanrooms provides for an easy cleanroom installation as well as the flexibility of quickly being able to expand or relocate the room. The hardwall or softwall cleanroom designs can offer free spans of up to 32 feet.

Portable SUS304 32 Feet Softwall Clean Room , 7500m3/H Class 1000 Clean Room
CLEAN ROOM Specification:
Model item
ISO 7 CLEAN ROOM
AL-CS4*6/C7
AL-CS5*10/C7
AL-CS6*12/C7
AL-CS7*20/C7
Size(mm)
4000*6000*2500
5000*10000*2500
6000*12000*2500
7000*20000*2500
Material
Framework
Cold rolled steel /Aluminum/Stainless steel/sandwich panel
Around
Plexiglass,Soft curtain,Anti-static strip curtain/sandwich panel
Clean Class Level
10000
10000
10000
10000
HEPA filter
Size(mm)
610*610*69
1220*610*69
1220*610*69
1220*610*69
Efficiency(%)
99.99
99.99
99.99
99.99
Air flow (m3/h)
3600
7500
10800
21000
Pre filter
Size(mm)
Optional
Motor Spec
Power supply
220V/50Hz
220V/50Hz
220V/50Hz
220V/50Hz
Noise(dB)
62
63
62
63

Softwall Clean Room Features:


Cleanroom Sizes: Designed to Fit Various Applications


Frame Construction: Painted Tubular Steel, A 40 Mil System with Four-Way Extrusions Are Available.


Finish: Epoxy-Painted


Filtration: Various Types of Filtration Systems Are Available Depending on The Client Requirement.


Lighting: Sealed Fixtures, Energy Efficient Ballasts, Low Energy Bulbs, And Flush-Mounted to Ceiling and If Needed Side-Panels. For Photolithography Applications, UV-Filtering Lighting Systems Are Available.


Panels: Anti-Static or Non-Outgassing Flexible PVC’s Are Available in Various Colors. Black Poly Vinyl Is Available for Laser Applications.

Wiring: Installed in The Posts

More about anlaitech softwall clean room:

Clean room devices may operate both in negative and in positive pressure without compromising the safety and cleanliness performances. The pressure pattern set up and operational mode, mostly depends on the lay-out of the clean room or to meet specific standard requirements. They operate as standard in negative pressure in comparison to the pressures of the surrounding environments generating that so called “well of pressure“.

Positive step of pressure: the inside pressure is higher in comparison to not clean side area and lower than clean side area.

Overpressure: the inside pressure is higher in comparison to not clean side and clean side areas.

Well of pressure: the inside pressure is lower in comparison to not clean side area and clean side area.
