Specifications
Brand Name :
QUALITY
Model Number :
HEYA-B
Certification :
CE,ISO
Place of Origin :
Weifang
MOQ :
4 UNITS Container house
Price :
Negotiation
Payment Terms :
T/T OR L/C
Supply Ability :
100 Units container house
Delivery Time :
7 days
Packaging Details :
SOC or In bulk
Structure :
Galvanized Steel Frame
Size :
6055mmX2435mmX2896mm
Application :
camp,etc.
Door :
Steel Door
Usage :
Living
Roof :
Sandwich Tile
Type :
Prefab
Wall :
EPS Sandwich Panel
Color :
Customized
Layout :
Customized
Description

2 Bedroom prefabricated steel frame container house plans modular wood homes

Product Description

2 Bedroom prefabricated steel frame container house plans modular wood homes2 Bedroom prefabricated steel frame container house plans modular wood homes

Item Details
Dimension(mm)&Weight(kg) Recommend:L6055*W2435*H2896mm/L6055*W3000*H2896mm(Custom Sizes Available)
Floor Steel frame:made from cold rolled,welded steel profiles,4 mm thick,4 corner casts,welded steel cross members,thickness=1.8mm
Floor:18mm Mgo Board,1.8mm PVC floor(blue),flammability class B1-hardly combustible,smoke density class Q1-low smoke emission

Roof

Steel frame:made from cold rolled,welded steel profiles,3mm thick,4 corner casts,welded,steel cross members, thickness=2mm
Roof cover:0.4mm thick,galvanized steel sheet,360 degree seaming at joint of roof panels
Insulation:100 mm thick Glass Wool
Ceiling:corrugated metal sheet,YX12-110-880,0.35mm thickness
CEE connector:sunken in frame on short end side
Wall Insulation Glass wool sandwich panel,0.4mm thickness color steel sheet/150mm/50kg/m3 glass wool,white-grey,size 1150mm*2575mm
Doors Steel door:840mm*2035mm
Windows Sliding window:Upvc sliding window,white,1110mm *1100mm,with screen,fence,5+9A+5 double glass
Electrical Installation Technical data:sunken CEE external plug and socket connections,voltage 230/400 V (option:110V),50 Hz,3/5 poles,32 A,circuit diagram for assembly provided inside the consumer box,consumer box,sunken into wall panel

Materical Science:

2 Bedroom prefabricated steel frame container house plans modular wood homes

20 ft standard container installation

2 Bedroom prefabricated steel frame container house plans modular wood homes

Company information

Heya Group is one of the largest manufacturers of the prefabricated house,flat pack container house,steel villas, and steel structure warehouse in China. We have been doing well in this field for more than 21 years,and we have exported our products to more than 90 countries as well as our domestic market with ISO9001,CE and SGS approval.

Heya Group

2 Bedroom prefabricated steel frame container house plans modular wood homes

Heya Workshop

2 Bedroom prefabricated steel frame container house plans modular wood homes

Our Service

1.Design & Engineering about Prefab flat pack container house

Experienced and skilled team of designers including CAD designers and 3D designers has the capacity to deliver outstanding designs for your project.Simple design service is free of charge to all clients to ensure customer satisfaction and compliance with local standards. If you require more complex engineering of structures such as load baring capacities we can also provide this service but need designer fee . We look forward to delivering exceptional designs and advice for your project.

2. Installation supervision and after-sales service

Projects can be assisted by our construction team. We have the capacity to provide civil work advisory service to assist on the construction requirements of the project and full project management if required. With the capacity to utilize skilled personal from around the globe you can be assured your construction crew will efficiently simplify the construction process of any project. If needed, we will dispatch our professional workers to conduct assembling guide or technical support for you on site. We're at your service!

3 Arrange Shipping and good package without wood material

Tiandi container house can be transported and shipped through worldwide. We can arrange the shipping with competitive sea freight to your port.

2 Bedroom prefabricated steel frame container house plans modular wood homes

You May Like:

2 Bedroom prefabricated steel frame container house plans modular wood homes 2 Bedroom prefabricated steel frame container house plans modular wood homes 2 Bedroom prefabricated steel frame container house plans modular wood homes

Our Clients

Our clients are from all over the world. They trust us, support us, and we have a long relationship of cooperation.

2 Bedroom prefabricated steel frame container house plans modular wood homes

Packaging & Shipping

One 40’ft HQ container can load 6 units 20ft standard flat-pack container.

2 Bedroom prefabricated steel frame container house plans modular wood homes

SEND INQUIRY

2 Bedroom prefabricated steel frame container house plans modular wood homes

FAQ
1.Q: What is the MOQ?
A: 1 unit.
2.Q: What is the Delivery time?
A: 15 days after receiving deposit and signature of the drawings and Sales confirmation.
3.Q: What is the Payment terms you can accept?
A: T/T or L/C.50% T/T deposit,balance payment should be payable before loading..Also 100% L/C is accepted.
4.Q: What is the Warranty?

A:All the materials are in 1 year.We can provide technical support to maintain the building and supply the parts what need to replace.
