14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage
14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage
14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage
14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage
14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage
14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage
14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage
14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage
14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage
14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage
14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage
14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage
Specifications
Brand Name :
SUNLUXX
Model Number :
FAL-100W
Certification :
CE RoHs
Place of Origin :
China
MOQ :
1
Price :
US$144.16/PC, EXW Price
Payment Terms :
T/T, Western Union
Supply Ability :
6000 PCS per Month
Delivery Time :
3 - 5 working days
Packaging Details :
54cm*46cm*19cm / 2pcs / 13.5kg / carton
Watts: :
100W
Lumens: :
14000lm
LED Chip: :
Nichia 3030
CCT: :
3000K - 5700K or as customized
CRI: :
>70 or >80
Operating Temperature: :
-40℃ to +45℃
IP: :
66
IK: :
10
Installation Way: :
Adjustable bracket
Driver: :
Meanwell
Warranty: :
5 yrs
Lamp Body Material: :
Pure Aluminum
Description

Building Lighting Super Bright 14000lm 100W LED Area Flood Lights, IP66 , IK10 , Tennis Court Lighting


Features

• Openable junction box design, easy for installation and maintenance.
• Easy open type power door, convenient for maintenance.
• Pure Aluminum big merchain die-casting radiator and whole structure dissipation technology, high performance.
• IP66 protection class, IK10, strong enough for strong wind resistance.
• No goldine eutectic welding, avoid the wire breakage risks.
• Single LED's damage does not affect other chips' work and current.
• 90-305VAC wide voltage, IP66, IK10 protection.
• High quality and 100% green lighting.

• 5 years warranty.

Technich Data

Power 100W
Input Voltage 90 - 305VAC
Input Current 0.45A@220VAC
PF >0.9@220VAC
DC Output Voltage 48V
DC Output Current 1.9A
Dimming (Optional) 3 in one dimming(PMW, 1-10V,Resistor), DALI
CCT 4000k, 5000k, 5700K, 3000K and 2700K can be customized
Ra>80,5000K Typical Flux 13000lm±10%
Efficiency 130lm/W±10%
Ra>70,5000K Typical Flux 14000lm±10%
Efficiency 140lm/W±10%
LED Brand NICHIA 3030
Light Type Asymmetric and symmetric polarized light
Operation Temp. -40 ℃ to + 45 ℃
Storage Temp. -40 ℃ to + 85 ℃
Lifespan 45℃ , 50,000 hours
IP Class 66
IK Class 10
Lamp Body Color Grey or as customized
Product Size(mm) 330*373*50
Net Weight(kg) 4.76
Packing size(mm) 540*460*190
Gross Weight(kg) 13.5
Product Quantity Per Carton 2pcs
Installation Method Bracket Mount



14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage

14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage

Product Size

14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage




Beam Angle


ANB AWB SNB SWB
14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage


Installation Manual

14000LM 100 W LED Flood Lights IP66 IK10 Tennis Court / Building Lighting Usage

Applications

  • Outdoor lighting
  • Architectrural lighting
  • Storage spaces
  • Golf courts
  • Landscape lighting
  • Gym lighting
  • Warehouse lighting
  • Square, park, wall of buildings, church, bridge, public area.
