DaLi Function High Bay LED Lights , One - Piece Integrated Wires Industrial LED Fixture
DaLi Function High Bay LED Lights , One - Piece Integrated Wires Industrial LED Fixture
DaLi Function High Bay LED Lights , One - Piece Integrated Wires Industrial LED Fixture
DaLi Function High Bay LED Lights , One - Piece Integrated Wires Industrial LED Fixture
Specifications
Brand Name :
SUNLUXX
Model Number :
HBL-100Watt
Certification :
CE RoHs
Place of Origin :
China
MOQ :
1
Price :
US$105.88/PCS unit EXW prices DALI Dimmable
Payment Terms :
T/T, Western Union
Supply Ability :
5000 Pieces per Month
Delivery Time :
5-8 work days
Packaging Details :
34cm*34cm*24cm/1pcs
Input Voltage :
100-277VAC
Beam angle :
60 ° , 90 ° , 120 °
Lumen :
14500LM
Color Temperature :
3000K,4000K,5000K,5700K
Driver Brand :
Meanwell
IP :
66
PF :
0.90
Ra :
Ra>80,Ra>70
Description

DaLi Function One-piece Integrated Wires High Bay LED Lights for Industrial Application

DALI High Bay LED Lights are best suited for gymnasiums,warehouses, manufacturing plants and any other industrial or commercial facility with high ceilings.LED High Bays 100 Watt 14500 lumen universal voltage 120-277V,above 300V is available.

Features

1. Compact and Fashion design.

2. Luminous efficacy up to 160 lm/W, high power factor (>0.95)

3. Uniform light distribution

4. The first patented proprietary optics and higher transmittance 95% water wave lens

5. Surface anti-aging electrostatic spray-paint processing,ensure longer lifespan

6. 60/90/120 degree IES distribution selection, national listing lab tested with IES standard.

7. Dali Dimmer or Microwave sensor is optional

8. Extra lengthen cable is available

9. Easily replace standard high bay fixtures.

Produce Code

HBL-60Watt HBL-80W 100W HBL-120W150W HBL-200W240W

Power 60Watt 80W 100W 120W 150W 200W 240W
Input Voltage 90-305VAC
Input Current

60W:0.27A@220VAC 80W: 0.36A@220VAC 100W:0.45A@220VAC

120W:0.55A@220VAC 150W:0.68A@220VAC 200W:0.91A@220VAC

240W:1.10A@220VAC
PF >0.90@220VAC
DC output voltage 60W:54V 80W100W120W150W: 48V
DC output current 60W:1.05A 80W: 1.5A 100W: 1.9A 120W: 2.3A 150W:2.9A 200W:3.9A 240W:4.65A
Dimming (Optinal) 3 in 1 dimming (PWM, 0-10V, Resistor),Dali
CCT 4000K,5000K,5700K,3000K

Ra >70

5000K

 Typical Flux

60W:9000Lm±5%,80W:12000Lm±5%,100W:15000Lm±5%,

120W:18000Lm±5%,150W:22500Lm±5%,200W:30000Lm±5%

240W:36000Lm±5%
LED Brand Nichia 3030 and Lumileds 3030
Beam Angle 60°,90°,120°
Operation Temp -40℃ ~ +45℃
Storage Temp -40℃ ~ +85℃
Life Circle 45℃ 50000Hours
IP Class IP66
IK Class IK08
Certificate CE,ROHS
Body Color Black (default with RAL9005),Gray ( optional for RAL9007)

DaLi Function High Bay LED Lights , One - Piece Integrated Wires Industrial LED Fixture

Package

DaLi Function High Bay LED Lights , One - Piece Integrated Wires Industrial LED Fixture
