200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
Specifications
Brand Name :
SUNLUXX
Model Number :
FAL-200W
Certification :
CE RoHs
Place of Origin :
China
MOQ :
1
Price :
US$185 / PC, EXW Price
Payment Terms :
T/T, Western Union
Supply Ability :
6000 Pieces per Month
Delivery Time :
3-5 working days
Packaging Details :
54cm*46cm*19cm/2pcs
Power: :
200W
Luminous Flux: :
28000lm
Voltage :
200-305VAC
LED Brand :
Nichia 3030
Protection level :
IP66
Driver: :
MEANWELL
Operating Temp.: :
-40℃ - + 45℃
Storage Temp.: :
-40℃ - + 85℃
Dimmable: :
DALI, 1-10V, 1-10V PMW, Resistor
Mounting: :
Adjustable Bracket
Description

EU Standard 200W LED Stadium flood light 28000lm For Large Area Lighting, 200 - 305VAC


Features

High lumen efficiency, 140lm/W, flicker free, and options of Ra70 or Ra80.

Using top quality materials, Japan CHINIA LEDs, Taiwan MEANWELL driver, die-casting Pure Aluminum lamp body, 5 yrs warranty.

High protection level of IP66. All Accessaries are waterproof and are sealed to protect LEDs, and terminal block against dust and moisture, increasing reliability and extending lifespan.

High impact resistance, meet IK10 michanics impact protection code.

Strong wind resistance, high vibration resistance.

Product Details

Power 200W
Input Voltage 90 - 305VAC
Input Current 0.91A@220VAC
PF >0.9@220VAC
DC Output Voltage 48V
DC Output Current 3.9A
Dimming (Optional) 3 in one dimming(PMW, 1-10V,Resistor), DALI
CCT 4000k, 5000k, 5700K, 3000K and 2700K can be customized
Ra>80,5000K Typical Flux 26000lm±10%
Efficiency 130lm/W±10%
Ra>70,5000K Typical Flux 28000lm±10%
Efficiency 140lm/W±10%
LED Brand NICHIA 3030
Light Type Asymmetric and symmetric polarized light
Operation Temp. -40 ℃ to + 45 ℃
Storage Temp. -40 ℃ to + 85 ℃
Lifespan 45℃ , 50,000 hours
IP Class 66
IK Class 10
Lamp Body Color Grey or as customized
Product Size(mm) 441*373*50
Net Weight(kg) 6.37
Packing size(mm) 540*460*190
Gross Weight(kg) 13.5
Product Quantity Per Carton 2pcs
Installation Method Bracket Mount


200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures

Beam Angle

200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
Accessories


200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures

Light Distribusion Curve


200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures


Installation Manual

200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
Applications

Garden Lighting,Park Lighting,Billboard Lighting,Landscape Lighting,Building Lighting,Stadium Lighting

200 Watt LED Stadium Flood Light , 28000LM Large Area LED Lighting Fixtures
