Specifications
Brand Name :
SUNLUXX
Model Number :
FAL-75W
Certification :
CE RoHs
Place of Origin :
China
MOQ :
1
Price :
US$113.84/PC , EXW price
Payment Terms :
T/T, Western Union
Supply Ability :
6000 Pieces per Month
Delivery Time :
3-5 work days
Packaging Details :
54cm*46cm*19cm/2pcs/carton
Power :
75W
Body Material :
High heat conduction Aluminum
Voltage :
90-305VAC
LED Brand :
Nichia SMD 3030
Protection level :
IP66
Driver :
Sosen
Efficiency :
140lm/W
PF :
> 0.95
Optical Angle :
ANB, AWB, SNB, SWB
Warranty :
5 years
Description

Wterproof Typhoon Resistance 140LM / W IK10 75W LED Stadium IP66 Flood Light , Billboard And Yard Lighting


Features

  1. Ferrari idea design, more professional lighting design, Typhoon resistance.
  2. System Light Efficacy, 140lm/W
  3. Multiple Choice of Optical beam angle: ANB, AWB, SNB, SWB
  4. Easy Installation & Maintenance
  5. Five Years Warranty
  6. IP66, IK10
  7. Color Rendering Index: Ra>70 or Ra>80, according to your requirement
  8. Input Voltage: 90 - 305 Vac, 50/60Hz
  9. Application: sport fields, billboard, square and public area, yard lighting.

Technical Data

Power 75W
Input Voltage 90 - 305VAC
Input Current 0.68A@220VAC
PF >0.9@220VAC
DC Output Voltage 48V
DC Output Current 2.9A
Dimming (Optional) 3 in one dimming(PMW, 1-10V,Resistor), DALI
CCT 4000k, 5000k, 5700K, 3000K and 2700K can be customized
Ra>80,5000K Typical Flux 19500lm±10%
Efficiency 130lm/W±10%
Ra>70,5000K Typical Flux 21000lm±10%
Efficiency 140lm/W±10%
LED Brand NICHIA 3030
Light Type Asymmetric and symmetric polarized light
Operation Temp. -40 ℃ to + 45 ℃
Storage Temp. -40 ℃ to + 85 ℃
Lifespan 45℃ , 50,000 hours
IP Class 66
IK Class 10
Lamp Body Color Grey or as customized
Product Size(mm) 330*373*50
Net Weight(kg) 4.76
Packing size(mm) 540*460*190
Gross Weight(kg) 13.5
Product Quantity Per Carton 2pcs
Installation Method Bracket Mount



Typhoon Resistant LED Stadium Lights 140LM/W IK10 75W Billboard / Yard LED Flood LightTyphoon Resistant LED Stadium Lights 140LM/W IK10 75W Billboard / Yard LED Flood Light

Beam Angle

Typhoon Resistant LED Stadium Lights 140LM/W IK10 75W Billboard / Yard LED Flood Light
Typhoon Resistant LED Stadium Lights 140LM/W IK10 75W Billboard / Yard LED Flood Light
Typhoon Resistant LED Stadium Lights 140LM/W IK10 75W Billboard / Yard LED Flood Light
Typhoon Resistant LED Stadium Lights 140LM/W IK10 75W Billboard / Yard LED Flood Light
Typhoon Resistant LED Stadium Lights 140LM/W IK10 75W Billboard / Yard LED Flood Light

Accessories
Typhoon Resistant LED Stadium Lights 140LM/W IK10 75W Billboard / Yard LED Flood Light

Light Distribusion Curve


Typhoon Resistant LED Stadium Lights 140LM/W IK10 75W Billboard / Yard LED Flood Light
Installation Manual


Typhoon Resistant LED Stadium Lights 140LM/W IK10 75W Billboard / Yard LED Flood Light
Applications

Side Walk Lighting, Garden Lighting,Park Lighting,Billboard Lighting,Landscape Lighting,Building Lighting,Stadium Lighting.

Typhoon Resistant LED Stadium Lights 140LM/W IK10 75W Billboard / Yard LED Flood Light
