Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Specifications
Brand Name :
SUNLUXX
Model Number :
FAL-150W
Certification :
CE RoHs
Place of Origin :
China
MOQ :
1
Price :
US$143.51 / PC, EXW Price
Payment Terms :
T/T, Western Union
Supply Ability :
6000 Pieces per Month
Delivery Time :
3-5 working days
Packaging Details :
54cm*46cm*19cm/2pcs
Power: :
150W
Luminous Flux: :
21000lm
Voltage :
200-305VAC
LED Brand :
Nichia 3030
Protection level :
IP66
Driver: :
MEANWELL
Luminous Efficiency: :
140lm/W
Beam Angle: :
ANB,AWB,SNB,SWB
IK: :
10
Lamp Color: :
Grey or as customized
Description

Waterproof 140lm / W LED Stadium flood light 150W Area Light For Industrial Lighting, 200 - 305VAC , Europe Standard


Features

LED Chip: NICHIA 3030 LED Chips which is the most famous Brand in chips field, high efficiency high lumen and long lifespan, high quality.

Power Supply: Using MEANWELL UL approved driver, IP66 and high quality, it improved lights performance. Power efficiency >0.95.

Color temperature: 3000K, 4000K, 5000K, 5700K.

Optics: Optical assembly: hermetically sealed providing IP66. Great light uniformity: Thanks to the advanced LED optical systems the fixture maximize the utilization of light onto the target area, improving the uniformity of light.

Housing: Die-casting aluminum lamp body, electrostatic surface paint technology, strong and anti-corrosion and dust proof.

Cable: silicon rubber cable for power input, IP67 water proof connectors.

Warranty: 5 years. Do not attempt to take housing apart as this will ruin the seal and void all warranty.

Quality Control: Rigorous product testing includes high-low temperature tests, waterproof tests, shockproof tests, burn-in testing, tensile test, salt spray test and more to ensure long-term performance.

Angle Adjustable: Adjustable stainless steel mounting bracket allows you to direct light where you need it.

Product Details

Power 150W
Input Voltage 90 - 305VAC
Input Current 0.68A@220VAC
PF >0.9@220VAC
DC Output Voltage 48V
DC Output Current 2.9A
Dimming (Optional) 3 in one dimming(PMW, 1-10V,Resistor), DALI
CCT 4000k, 5000k, 5700K, 3000K and 2700K can be customized
Ra>80,5000K Typical Flux 19500lm±10%
Efficiency 130lm/W±10%
Ra>70,5000K Typical Flux 21000lm±10%
Efficiency 140lm/W±10%
LED Brand NICHIA 3030
Light Type Asymmetric and symmetric polarized light
Operation Temp. -40 ℃ to + 45 ℃
Storage Temp. -40 ℃ to + 85 ℃
Lifespan 45℃ , 50,000 hours
IP Class 66
IK Class 10
Lamp Body Color Grey or as customized
Product Size(mm) 330*373*50
Net Weight(kg) 4.76
Packing size(mm) 540*460*190
Gross Weight(kg) 13.5
Product Quantity Per Carton 2pcs
Installation Method Bracket Mount


Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type

Beam Angle

Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Accessories


Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type

Light Distribusion Curve


Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type


Installation Manual

Waterproof 140LM/W LED Sports Ground Floodlights NICHIA 3030 LED Chips Type
Applications

Garden Lighting,Park Lighting,Billboard Lighting,Landscape Lighting,Building Lighting,Stadium Lighting
