140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
Specifications
Brand Name :
SUNLUXX
Model Number :
FAL-75W
Certification :
CE RoHs
Place of Origin :
China
MOQ :
1
Price :
US$113.84/PC , EXW price
Payment Terms :
T/T, Western Union
Supply Ability :
6000 Pieces per Month
Delivery Time :
3-5 work days
Packaging Details :
54cm*46cm*19cm/2pcs/carton
Power :
75W
Lumen flux :
10500lm
Voltage :
90-305VAC
LED Brand :
Nichia 3030
Protection level :
IP66
Driver :
Sosen
Efficiency :
140lm/W
Power Factor :
> 0.95
Description

High Effeiciency IK10 75W LED Stadium Flood Light , IP66 , 5 Years Warranty


Features

1. 140lm/W high brightness , stable performance long longevity and low power consumption

2. Stable current , by high efficient and wide voltage constant current driver

3. Mounting bracket can be rotated 180 degrees to facilitate the installation

4. It provides even, bright illumination across a wide area

5. Waterproof design, ideal even for outdoor use

6. IP66, IK10 protection, strong wind resistance, Ferrari Idea design make it higher performance.

7. 5 years warranty.


Technical Data

Power 75W
Input Voltage 90 - 305VAC
Input Current 0.68A@220VAC
PF >0.9@220VAC
DC Output Voltage 48V
DC Output Current 2.9A
Dimming (Optional) 3 in one dimming(PMW, 1-10V,Resistor), DALI
CCT 4000k, 5000k, 5700K, 3000K and 2700K can be customized
Ra>80,5000K Typical Flux 19500lm±10%
Efficiency 130lm/W±10%
Ra>70,5000K Typical Flux 21000lm±10%
Efficiency 140lm/W±10%
LED Brand NICHIA 3030
Light Type Asymmetric and symmetric polarized light
Operation Temp. -40 ℃ to + 45 ℃
Storage Temp. -40 ℃ to + 85 ℃
Lifespan 45℃ , 50,000 hours
IP Class 66
IK Class 10
Lamp Body Color Grey or as customized
Product Size(mm) 330*373*50
Net Weight(kg) 4.76
Packing size(mm) 540*460*190
Gross Weight(kg) 13.5
Product Quantity Per Carton 2pcs
Installation Method Bracket Mount



140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights


Beam Angle

140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights

Accessories
140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights

Light Distribusion Curve


140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights

Installation Manual


140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
Applications

Side Walk Lighting, Garden Lighting,Park Lighting,Billboard Lighting,Landscape Lighting,Building Lighting,Stadium Lighting.

140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights
